General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Data Transfer Rate
1.75 Gbps
Line Coding Format
DBPSK, DQPSK, CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Remote Management Protocol
NETCONF
Frequency Band
2.4 GHz, 5 GHz
Status Indicators
Power, WLAN
Features
VLAN support, DiffServ support, MAC address filtering, wall mountable, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), 3T3R MIMO technology, DHCP client, ceiling mountable, Maximum Likelihood Demodulation (MLD), cloud managed, packet aggregation A-MPDU, packet aggregation A-MSDU
Encryption Algorithm
TLS, PEAP, TTLS, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WEP
Authentication Method
RADIUS, Radio Service Set ID (SSID), Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM, EAP-AKA
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3au
Aerial
Expansion / Connectivity
Interfaces
2 x 1000Base-T (PoE) - RJ-45
1 x console - RJ-45
Miscellaneous
Included Accessories
Wall/ceiling mounting plate
Compliant Standards
EN55022, EN55024, FCC Part 15 B, FCC Part 15 C, IEC 60950-1, EN 60950-1, FCC Part 15 E, BSMI CNS 13438, EN 60601-1-2, BSMI CNS 14336-1, EN61000-3-2, EN61000-3-3, EN 301 489-1, LP0002, ETSI EN 300 328, ETSI EN 301 893, EN 301 489-17
Power
Power Over Ethernet (PoE) Supported
PoE
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
10 - 90% (non-condensing)
