General
Device Type
Switch - 6 ports - L2+ - Managed
Enclosure Type
Plug-in module
Ports
4 x 10/100/1000 + 1 x 10/100/1000/SFP (uplink) + 1 x 10/100/1000 (downlink)
MAC Address Table Size
8192 entries
Jumbo Frame Support
10240 bytes
Routing Protocol
IGMP, MLD
Remote Management Protocol
SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, SSH
Features
Flow control, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, DiffServ support, manageable, store and forward, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, horizontal mounting, LLDP support, Energy Efficient Ethernet, Network Access Control (NAC)
Compliant Standards
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1ab (LLDP), IEEE 802.3az
Status Indicators
Status, link/activity
Expansion / Connectivity
Interfaces
4 x 1000Base-T RJ-45 ¦ 1 x 1000Base-X SFP uplink ¦ 1 x 1000Base-T RJ-45 downlink ¦ 1 x USB management
Expansion Slots
1 (total) / 1 (free) x microSD
Power
Power Device
Internal power supply
Voltage Required
AC 230V (50 - 60 Hz)
Power Consumption Operational
5.5 Watt
Miscellaneous
Compliant Standards
Directive 2006/95/EG, EMC 2004/108/EC, EN 60950-1:2011, EN 55022:2011-12, EN 55024:2011-09
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-20 °C
Max Storage Temperature
85 °C
