General
Device Type
Switch - 8 ports - Managed
Enclosure Type
Desktop, rack-mountable, DIN rail mountable, wall-mountable
Ports
8 x 10/100/1000Base-T + 2 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 20 Gbps
Remote Management Protocol
SNMP, DHCP, IPv4, IPv6, Syslog
Features
DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), fanless, DHCP relay, 802.1x authentication, VLAN Tagging, non-blocking architecture, remote firmware upgrade
Compliant Standards
IEEE 802.1Q, IEEE 802.1x, IEEE 802.3bt
Status Indicators
Power, status, link/activity
Expansion / Connectivity
Interfaces
8 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 2 x 1000Base-X SFP
Power
Power Device
External power adapter
Voltage Required
DC 50 - 54 V
Electric Current Required
5.6 A
Power Consumption Stand by
12 Watt
Miscellaneous
Included Accessories
DIN-rail bracket, wall mount brackets, 19" mounting brackets
Compliant Standards
VCCI, BSMI, JATE, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, IEC 60068-2-30, WEEE, ANATEL, KC, IP30, NOM-019-SCFI-1998, VCCI Class A, NEMA TS-2, China RoHS, RCM, IEC 60068-2-3, EN 300 386, NAL, IEC/EN 61000-4-9, IEC/EN 61000-4-29, AS/NZS CISPR 32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, IFETEL, EN 55032, CAN/CSA-C22.2 No. 62368-1, CAN/CSA C22.2 No. 60950-1, IEC 62368-1 Second Edition, UL 62368-1 Third Edition, IEC 62368-1 Third Edition, CNS 15598-1:2020, FCC CFR 47 Part 15 Class A, CNS 15936 Class A
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - advance hardware replacement - lifetime - response time: next business day ¦ Technical support - 1 year
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95%
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
