General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Data Transfer Rate
867 Mbps
Line Coding Format
CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Spread Spectrum Method
OFDM, DSSS
Frequency Band
2.4 GHz, 5 GHz
Performance
Concurrent data rate (5 GHz): 867 Mbps ¦ Concurrent data rate (2.4 GHz): 400 Mbps
Capacity
Wireless clients per Wi-Fi radio: 255 ¦ BSSIDs per radio: 16
Status Indicators
Power, system, status
Features
Auto-uplink (auto MDI/MDI-X), DFS support, wall mountable, Quality of Service (QoS), Trusted Platform Module (TPM), reset button, 2T2R MIMO technology, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Energy Efficient Ethernet, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), cyclic shift diversity (CSD), MU-MIMO technology, enhanced ClientMatch, Aruba Beacons Bluetooth Low-Energy (BLE) technology, packet aggregation A-MPDU, packet aggregation A-MSDU, wireless intrusion protection, Air Monitor (AM)
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac
Aerial
Expansion / Connectivity
Interfaces
1 x 1000Base-T (uplink) - RJ-45 ¦ 2 x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T (PoE) ¦ 1 x USB 2.0 - Type A ¦ 1 x console ¦ 2 x pass-through - RJ-45
Miscellaneous
Included Accessories
Single-gang wall-box
Compliant Standards
EN 60950, IEC 60950, UL 60950, CB, UL 2043, FCC, EN 60601-1-2, cTUVus, EN 300 328, EN 301 489, EN 60601-1-1, LVD 72/23/EEC, EN 301 893, R&TTE Directive 1995/5/EC
Power
Power Over Ethernet (PoE) Supported
PoE
Power Consumption Operational
15.6 Watt
Software / System Requirements
OS Required
ArubaOS, InstantOS
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 93% (non-condensing)
