HPE 5130-24G-SFP-4SFP+ EI - Switch

Productcode: JG933A | EAN/UPC: 0888182606803

€ 2.258,87 excl.btw

HPE 5130-24G-SFP-4SFP+ EI - Switch - L3 - Managed - 24 x Gigabit SFP + 8 x shared 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ - rack-mountable

Delivers flexibility, scalability and low TCO at the access layer of medium- and large-enterprise campus networks
Supports stacking, fixed 10 GbE ports, static layer 3 routing and RIP v1/v2, PoE+, ACLs, IPv6 and power savings with Energy Efficient Ethernet
The HPE Intelligent Resilient Framework (IRF) virtualizes up to nine physical switches into one logical device for simpler, flatter, more agile networks
Four fixed 10 GbE uplinks (SFP+) deliver performance for bandwidth intensive applications
Includes Software-defined Network (SDN) capabilities with OpenFlow 1.3 support for future proofing your network
Supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information
Provides traffic prioritization with supported congestion actions include: strict priority (SP) queuing, weighted round robin (WRR), weighted random early detection (WRED), and SP+WRR and traffic policing with Committed Access Rate (CAR) and line rate
Supports flexible authentication methods including 802.1X for greater security and policy-driven application authentication
Per-user access control lists (ACLs) provide identity-driven security and access control

Op voorraad: 1 stuk(s)

Levertijd:

Product:
HPE 5130-24G-SFP-4SFP+ EI - Switch

€ 2733,23 incl. 21% btw € 2258,87excl. 21% btw

Winkelwagen Offerte

Omschrijving

HPE 5130-24G-SFP-4SFP+ EI - Switch - L3 - Managed - 24 x Gigabit SFP + 8 x shared 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ - rack-mountable

Product features

Robust security
Equipped with Secure Shell v.2 (SSH2), HWTACACS, RADIUS, and TACACS+ authentication methods, this switch ensures secure network access and management, safeguarding against unauthorized access and threats.
High performance
With a throughput of 96 Mpps and a routing/switching capacity of 128 Gbps, the switch efficiently manages large volumes of data, ensuring smooth and reliable network performance.
Advanced networking
Supports Layer 3 advanced switching, IPv6, and a variety of IEEE standards, including 802.1Q and 802.3ad, making it versatile for complex network architectures.
Comprehensive management
Offers a wide range of remote management protocols including SNMP, RMON, and CLI, providing flexibility in network management and monitoring for optimized performance.
Enhanced connectivity
Features 24 Gigabit SFP ports, 8 shared 10/100/1000 ports, and 4 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ ports, offering diverse connectivity options for various network requirements.

Specificaties

General

Device Type

Switch - 24 ports - L3 - Managed - stackable

Enclosure Type

Rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

24 x Gigabit SFP + 8 x shared 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+

Performance

Throughput: 96 Mpps
Routing/switching capacity: 128 Gbps

Capacity

IPv4 routing table entries: 512
IPv6 routing table entries: 256

MAC Address Table Size

16384 entries

Jumbo Frame Support

9216 bytes

Routing Protocol

Static IPv4 routing, static IPv6 routing

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI

Encryption Algorithm

SSL

Authentication Method

RADIUS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS

Features

DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, WRR queuing, IPv6 support, half duplex mode, full duplex mode, sFlow, RSTP support, MSTP support, ACL support, QoS, Jumbo Frames support, MLD snooping, PVST+, DLDP support, RRPP, EAD, STP Root Guard, LLDP support, DHCP relay, Port Security, dynamic ARP protection, DHCP protection, SPQ, port isolation, tagged VLAN, GARP, IRF technology

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ab (LLDP)

RAM

1 GB SDRAM

Flash Memory

128 MB

Expansion / Connectivity

Interfaces

24 x 1000Base-X SFP
8 x 1000Base-T RJ-45
4 x Gigabit / 10Gbit LAN SFP+
1 x serial (console) RJ-45 management

Power

Power Device

Internal power supply (not installed)

Max Supported Qty

Power Consumption Operational

60 Watt

Miscellaneous

MTBF

52.79 years

Compliant Standards

FCC Class A certified, CISPR 22 Class A, CISPR 24, NOM, EN55024, EMC, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, ANATEL, FDA, EN 60825-1, EN 61000-4-29, ANSI C63.4-2009, VCCI V-3 Class A ITE, EN 61000-3-3:2008, VCCI V-4, EN 61000-3-2:2006+A1:2009+A2:2009, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, EN55022:2010 Class A, IEC 61000-4-3:2006, EN 61000-4.4:2012, CAN/CSA-C22.2 No. 60950-1, EN 300386

Localisation

English / Europe

Dimensions & Weight

Width

44 cm

Depth

36 cm

Height

4.36 cm

Weight

8 kg

Manufacturer Warranty

Service & Support

Limited warranty - replacement - lifetime - response time: next business day
Technical support - phone consulting - 3 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

45 °C

Humidity Range Operating

10 - 90% (non-condensing)

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

Humidity Range Storage

5 - 95% (non-condensing)

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
