General
Enclosure Type
Rack-mountable - modular - 2U
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Performance
Aggregate throughput: 200 Mbps
Network / Transport Protocol
IPSec, PPPoE, DHCP
Routing Protocol
OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), IPv4-to-IPv6 Multicast
Remote Management Protocol
SNMP, RMON
Features
VPN support, VLAN support, Syslog support, IPv6 support, CBWFQ, WRED, wall mountable, ACL support, QoS, RADIUS support, NetFlow, IPFIX
Compliant Standards
IEEE 802.3, IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag, ANSI T1.101, ITU-T G.823, ITU-T G.824, CISPR 22 Class A, CISPR 24, EN55024, EN 55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, R&TTE, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, AS/NZS 3548 Class A, GB 4943, VCCI V-3, EN 61000, KN22, KN24, CNS 13438, EN 300 386, CAN/CSA-C22.2 No. 60950-1
RAM
4 GB (installed) / 16 GB (max) - DDR3 SDRAM
Flash Memory
4 GB (installed) / 16 GB (max)
Expansion / Connectivity
Interfaces
WAN / LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Serial: 1 x console - RJ-45
Management: 1 x console - mini-USB Type B
Serial: 1 x auxiliary - RJ-45
USB 2.0: 2 x 4 pin USB Type A
3 x SFP (mini-GBIC)
Management: 1 x RJ-45
Expansion Slots
3 (total) / 3 (free) x NIM
1 (total) / 1 (free) x ISC
2 (total) / 2 (free) x Enhanced Service Module (SM-X)
2 (total) / 0 (free) x DIMM 240-pin
Power
Power Device
Internal power supply - 430 Watt
Installed Qty
1 (installed) / 1 (max)
Voltage Required
AC 120/230 V (50/60 Hz)
Miscellaneous
Rack Mounting Kit
Included
Software / System Requirements
OS Provided
Cisco IOS IP Base
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - advance parts replacement - 90 days - response time: 10 days
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 85%
