General
Device Type
Switch - 8 ports - Managed
Enclosure Type
Plug-in module
Ports
8 x 10/100 + 1 x combo Gigabit SFP + 1 x Gigabit SFP
Power Over Ethernet (PoE)
PoE
Performance
Bandwidth: 8 Gbps
Forwarding performance: 6.5 Mpps
Capacity
MAC addresses: 4000
Remote Management Protocol
SNMP 1, SNMP 2, RMON, SNMP 3, SNMP 2c, TFTP, CLI
Encryption Algorithm
MODBUS
Authentication Method
Kerberos, RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
DHCP support, VPN support, DoS attack prevention, IPv6 support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, DOM support, MLD snooping, UDLD, Rapid PVST+, SRR, RSPAN
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag
Status Indicators
Port status, system, PoE, link/activity
Expansion / Connectivity
Interfaces
4 x 100Base-TX RJ-45 PoE
4 x 100Base-TX RJ-45
2 x SFP (mini-GBIC)
1 x 1000Base-T RJ-45
Miscellaneous
Compliant Standards
CISPR 22 Class A, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, VCCI-I, EN55024, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1, AS/NZS 3548 Class A, EN 300 386
Dimensions & Weight
Environmental Parameters
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
Compatibility Information
Designed For
Cisco 2010, 2010 Connected Grid
