General
Device Type
Switch - 8 ports - Managed
Enclosure Type
Side to back airflow desktop, rack-mountable
Ports
8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 20 Gbps
Packets per second: 30 Mpps
Packet buffer size: 512 KB
Capacity
Latency: 4 µs
VLANs supported: 4000
Link aggregation groups: 8
Total link aggregation groups: 8
MAC Address Table Size
8K entries
Remote Management Protocol
SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH
Authentication Method
RADIUS
Features
Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, SNTP support, STP support, RSTP support, MSTP support, DHCP snooping, TFTP support, QoS, DAI, STP Root Guard, fanless, LLDP support, DHCP relay, LACP, Energy Efficient Ethernet, 802.1x authentication, Storm Control, LLDP-MED, STP BPDU Guard, VLAN Tagging
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.3bz
Expansion / Connectivity
Interfaces
8 x 10/100/1000 Base-T (PoE) RJ-45
2 x Gigabit LAN SFP
1 x console RJ-45 management
Power
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
139.2 Watt
Miscellaneous
Included Accessories
19" rack mounting kit
Rack Mounting Kit
Included
Compliant Standards
UL, VCCI, BSMI, CB, FCC, RoHS2, RCM
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
