General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Line Coding Format
64 QAM, 256 QAM, BPSK, QPSK, 1024 QAM, OFDMA
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, 802.11ax
Spread Spectrum Method
OFDMA
Frequency Band
2.4 GHz, 5 GHz
Capacity
Maximum number of configured SSIDs: 16
Features
Firewall protection, DFS support, surge protection, wall mountable, Wireless Intrusion Detection System (WIDS), Wireless Intrusion Prevention System (WIPS), 802.1x authentication, iBeacon technology, MU-MIMO technology, T-Rail mountable, spectrum analyser, Packet Sniffer Mode, security slot (Kensington security lock compatible), Bluetooth (BLE) clients support, Target Wait Time (TWT)
Encryption Algorithm
TLS, PEAP, TTLS, WPA, WPA2, WEP, EAP-AKA, WPA3, EAP-FAST
Authentication Method
MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM, EAP-AKA, EAP-GTC, EAP-TLS, EAP-TTLS
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.3at, IEEE 802.11j, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v, IEEE 802.11ac Wave 2, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
Expansion / Connectivity
Interfaces
1 x 1/2.5GBase-T (PoE+) - RJ-45
1 x 1000Base-T (PoE+) - RJ-45
1 x management (RS-232) - RJ-45
1 x USB - Type A
Miscellaneous
Included Accessories
Wall mounting kit, T-Rail mounting kit
Compliant Standards
ETSI, RoHS
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Consumption Operational
24.5 Watt
Dimensions & Weight (Shipping)
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 90% (non-condensing)
