General
Device Type
Radio access point
Networking
Form Factor
Wall mountable
Connectivity Technology
Wireless
Data Transfer Rate
3.6 Gbps
Line Coding Format
4096 QAM, OFDMA
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11be (Wi-Fi 7), Bluetooth 5.2
Spread Spectrum Method
OFDMA
Network / Transport Protocol
NTP
Routing Protocol
Static IP routing
Remote Management Protocol
SNMP 1, SNMP 2c, SNMP 3, SSH, NTP
Frequency Band
2.4 GHz, 5 GHz
Max Coverage Area
Up to 50 sq.m
Performance
Maximum data rate (2.4 GHz): 688 Mbps
Maximum data rate (5 GHz): 2882 Mbps
Channel bandwidth: 160 MHz
Capacity
Connected devices: 250+
SSIDs per device: 16
SSIDs per radio: 8
MAC filter entries: 4000
Features
PoE Pass Through, Multiple Resource Unit (MRU), seamless roaming, Omada Mesh technology, secure guest network, rogue AP detection, reset button, Captive Portal, Access Control List (ACL) support, client isolation, VLAN support, enable/disable SSID broadcast, wireless radio enable/disable, Auto Channel Select (ACS), Quality of Service (QoS), Wi-Fi Multimedia (WMM) support, beamforming technology, MU-MIMO technology, rate limit, load balancing, Airtime Fairness, band steering, MAC address authentication, schedule reboot, Wireless Scheduler, dynamic IP mode, LED control, MAC-based Access Control (MAC), firmware upgradable, system log, e-mail notification, polycarbonate enclosure, Transmit Power Control (TPC)
Encryption Algorithm
WPA-Personal, WPA-Enterprise, WPA2-Personal, WPA2-Enterprise, WPA3-Personal, WPA3-Enterprise
Authentication Method
Radio Service Set ID (SSID), RADIUS, Secure Shell (SSH)
Compliant Standards
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.3at, IEEE 802.3bt
Aerial
Expansion / Connectivity
Interfaces
2 x 10/100/1000Base-T - RJ-45
2 x 100/1000/2500Base-T (PoE++) - RJ-45
Miscellaneous
Included Accessories
Wall mounting kit
Compliant Standards
FCC, RoHS
Power
Power Over Ethernet (PoE) Supported
PoE++
Power Device
Power injector (not included)
Software / System Requirements
Software Included
Omada Controller
OS Required
Microsoft Windows XP / Vista / 7 / 8 / 10 / 11, Linux
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
