General
Device Type
Radio access point
Networking
Form Factor
Wall / ceiling / pole mountable
Connectivity Technology
Wireless
Line Coding Format
1024 QAM, OFDMA
Data Link Protocol
Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth
Spread Spectrum Method
OFDMA
Network / Transport Protocol
HTTP, NTP
Routing Protocol
Static IP routing
Remote Management Protocol
SNMP 1, SNMP 2c, SNMP 3, SSH, HTTP, NTP
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum data rate (2.4 GHz): 574 Mbps
Maximum data rate (5 GHz): 2402 Mbps
Capacity
Concurrent clients: 250+
SSIDs per wireless band: 8
Maximum number of configured SSIDs: 16
Maximum MAC filters: 4000
Features
Omada Mesh technology, seamless roaming, VLAN support, reset button, wireless radio enable/disable, enable/disable SSID broadcast, Guest Network, Airtime Fairness, band steering, beamforming technology, dynamic IP mode, MAC address authentication, Quality of Service (QoS), schedule reboot, Transmit Power Control (TPC), uplink/downlink MU-MIMO, Wi-Fi Multimedia (WMM) support, Wireless Scheduler, email alert notification, Zero-touch provisioning (ZTP), 2x2 MU-MIMO technology, load balance network mode, usage statistics, Access Control List (ACL) support, backup/restore, Captive Portal, client isolation, MAC-based Access Control (MAC), rogue AP detection
Encryption Algorithm
WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Authentication Method
Radio Service Set ID (SSID), Secure Shell (SSH), RADIUS, MACAuth
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11k, IEEE 802.11r, IEEE 802.11v, IEEE 802.3at, IEEE 802.1x
Aerial
Expansion / Connectivity
Interfaces
1 x 1000Base-T (PoE+) - RJ-45
Miscellaneous
Included Accessories
Mounting kit
Compliant Standards
FCC, RoHS, IP68
Power
Power Over Ethernet (PoE) Supported
Passive PoE / PoE+
Power Device
Power injector (not included)
Power Consumption Operational
12.5 Watt
Software / System Requirements
OS Required
Linux, Microsoft Windows XP / Vista / 7 / 8 / 10 / 11
Environmental Parameters
Min Operating Temperature
-30 °C
Max Operating Temperature
70 °C
Humidity Range Operating
10 - 90% RH (non-condensing)
