General
Device Type
Radio access point
Built-in Devices
Air quality sensor, temperature sensor, humidity sensor
Processor / Memory / Storage
Networking
Connectivity Technology
Wireless
Data Transfer Rate
7.78 Gbps
Line Coding Format
OFDMA, 1024 QAM
Data Link Protocol
Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.1 LE
Spread Spectrum Method
OFDMA
Frequency Band
2.4 GHz, 5 GHz, 6 GHz
Capacity
Spatial streams: 12
Features
XOR, zero-wait DFS, Dynamic Frequency Selection (DFS), radio resource management (RRM), CleanAir Pro technology, Client Steering, uplink/downlink MU-MIMO, BSS Coloring, Target Wake Time (TWT), image signing, secure boot, Cisco Trust Anchor module, 4x4:4 MU-MIMO technology, Maximal Ratio Combining, packet aggregation A-MPDU, packet aggregation A-MSDU, cyclic shift diversity (CSD), beamforming technology, Tri-Band 4x4, LLDP support, band steering, universal power over Ethernet (UPOE)
Encryption Algorithm
PEAP, AES, WPA2-Enterprise, WPA2-Personal, EAP-SIM, WPA3, WPA3-Personal, WPA3-Enterprise, EAP-FAST, WPA3-Enhanced Open, EAP-TLS, EAP-TTLS, MSCHAPv2, EAP-GTC, PEAPv1
Authentication Method
MS-CHAP, MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST, EAP-SIM
Compliant Standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bt, IEEE 802.11ax, Wi-Fi CERTIFIED 6E
Aerial
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Communications Technology
Bluetooth Low Energy (LE)
Expansion / Connectivity
Interfaces
1 x 100M/1G/2.5/5 Gigabit Ethernet (UPOE) - RJ-45
1 x management - RJ-45
1 x USB 2.0
Miscellaneous
Compliant Standards
FCC Part 15.247, AS/NZS 60950-1, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.407, FCC CFR47 Part 15 C, FCC CFR47 Part 15 B, UL Class III, CNS13438:2006, RSS-247, AS/NZS 2772.2, CAN/CSA-C22.2 No. 60950-1, VCCI-CISPR 32:2016, RSP-100, RSS-GEN, EN 301 893 V2.1.1, AS/NZS 4268:2017, EN 300 328 V2.2.2, EN 50385:2017, 47 CFR Part 2.1091, QCVN 112:2017, Japan Std. 66, Japan Std. 71, EN 55032:2015/A11:2020, EN 61000-3-3:2013+A1:2019, IEC 61000-3-2:2019, CAN/CSA-C22.2 No. 62368-1 Third Edition, UL 62368-1 Third Edition, EN 62368-1 Third Edition, IEC 62368-1 Third Edition, EN 301 489-17 V3.2.4 (2020-09), EN 301 489-1 V2.2.3 (2019-11), KS C 9832, EN 62311:2020, KS X 3124:2020, KS X 3126:2020, EN 61000-6-1:2019, Draft EN 303 687 V0.0.14, EN55035:2017+A11:2020, AS/NZS 62368-1 Third Edition, CISPR 32:2015+AMD1:2019, AS/NZS CISPR32:2015+AMD1:2020, ICES-003 issue 7 Class B, KS C 9835:2019, LP002
Power
Power Over Ethernet (PoE) Supported
UPOE
Power Device
External power adapter
Software / System Requirements
OS Required
Cisco IOS XE 17.12.1 or later
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Humidity Range Operating
10 - 90% (non-condensing)
