General
Enclosure Type
DIN rail mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, LoRaWAN
Performance
LTE downlink bandwidth: 150 Mbps ¦ LTE uplink bandwidth: 50 Mbps
Encryption Algorithm
128-bit AES
Features
Rugged, Firmware Over-the-Air (FOTA), realtime clock, aluminium housing
Compliant Standards
IEEE 802.3, FCC, RoHS, WEEE, REACH, PTCRB, ISED
Processor
1 x ARM ARM926EJ-S 450 MHz
Communications
Type
Wireless cellular modem
Mobile Communication Protocol
LTE
Cellular Band
LTE B13, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B26, LTE B5, LTE B39, LTE B28, LTE B8, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19
Max Transfer Rate
150 Mbps
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Communications Technology
LTE Cat 4
Expansion / Connectivity
Interfaces
WAN / LAN: 1 x 10Base-T/100Base-TX - RJ-45 ¦ LAN: 1 x 10Base-T/100Base-TX - RJ-45 ¦ Antenna: 2 x SMA
Expansion Slots
1 (total) / 1 (free) x Micro-SIM
Aerial
Aerial
External detachable
Power
Voltage Required
DC 9 - 33 V
Miscellaneous
Included Accessories
DIN-rail bracket
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
-30 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95%
