General
Device Type
Control processor
Processor / Memory / Storage
Processors Installed
2.4 GHz
Networking
Form Factor
Plug-in module
Connectivity Technology
Wired
Data Link Protocol
100 Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, Gigabit Ethernet
Network / Transport Protocol
IPv4, IPv6
Routing Protocol
MPLS, LISP, MSTP, STP, static IP routing, RIP-1, RIP-2, RIPng, BGP-4, IS-ISv4, EIGRP, OSPFv3, PIM-SM, PIM-SSM, RSTP
Remote Management Protocol
NETCONF, RESTCONF, YANG, CLI, HTTP, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
Performance
Bandwidth: 480 Gbps
Switching capacity: 9.6 Tbps
Forwarding rate: 3 Bpps
Capacity
MAC addresses: 64000
IPv4 routes (ARP entries): 256000
FNF entries (IPv4): 384000
FNF entries (IPv6): 192000
VLAN IDs: 4096
PVST instances: 300
STP Virtual Ports for PVST: 13000
STP Virtual Ports for MST: 13000
Switched virtual interfaces (SVIs): 1000
Jumbo frame size: 9216
IPv4 routing entries: 256000
IPv6 routing entries: 256000
Layer 2 multicast routes: 32000
Layer 3 multicast routes: 32000
QoS hardware entries: 16000
Security ACL hardware entries: 16000
Packet buffer size: 108 MB
Features
Virtual Routing and Forwarding (VRF), Cisco Unified Access Data Plane (UADP) 3.0, Access Control List (ACL) support, Quality of Service (QoS), Flexible NetFlow (FNF), PAT support, NAT support, MACsec support, Secure Unique Device Identification (SUDI), PXE support, image signing, secure boot, Cisco Trust Anchor module, Rapid Per-VLAN Spanning Tree Plus (PVRST+), DiffServ Code Point (DSCP) support, Shaped Round Robin (SRR), Committed Information Rate (CIR), Class of Service (CoS), Energy Efficient Ethernet, Management Information Base (MIB), Blue Beacon LED, VPN support, Virtual Private LAN Service (VPLS), Ethernet over MPLS (EoMPLS), 802.1x authentication
Encryption Algorithm
256-bit AES
Compliant Standards
IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.3, IEEE 802.3ae, IEEE 802.1D, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1x, IEEE 802.1ae, IEEE 802.3bt
Expansion / Connectivity
Interfaces
1 x console - RJ-45
1 x 1000Base-T (management) - RJ-45
1 x USB 3.0 - Type A
1 x management (mini-USB) - Type B
4 x 40Gb Ethernet/100Gb Ethernet - SFP+
4 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - QSFP
Miscellaneous
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, EN 300 386 V1.6.1, EN 55022 Class A, EN 300 386, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317
Power
Power Consumption Operational
650 Watt
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime - response time: next business day
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
10 - 95% (non-condensing)
Compatibility Information
Designed For
P/N: C9404R, C9404R=, C9404R-10A, C9404R-1A, C9404R-48U-BDL-EDU, C9404R-48U-BNDL-1A, C9404R-48U-BNDL-1E, C9404R-48U-BNDL-A, C9404R-48U-BNDL-E, C9404R-RF, C9404R-WS, C9407R, C9407R=, C9407R-10A, C9407R-1A, C9407R-96U-BDL-EDU, C9407R-96U-BNDL-1A, C9407R-96U-BNDL-1E, C9407R-96U-BNDL-A, C9407R-96U-BNDL-E, C9407R-96U-STK-EDU, C9407R-P, C9407R-RF, C9407R-WS, C9410R, C9410R=, C9410R-1A, C9410R-96U-BDL-EDU, C9410R-96U-BNDL-1A, C9410R-96U-BNDL-1E, C9410R-96U-BNDL-A, C9410R-96U-BNDL-E, C9410R-P, C9410R-RF, C9410R-WS
