General
Device Type
Control processor
Processor / Memory / Storage
Processors Installed
Intel 2.4 GHz
Networking
Form Factor
Plug-in module
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Performance
Forwarding rate: 3 Bbps
Capacity
MAC addresses: 64000
PVST instances: 300
VLAN IDs: 4096
STP Virtual Ports for PVST: 13000
FNF entries (IPv4/IPv6): 384000/192000
IPv6 routes: 256000
STP Virtual Ports for MST: 13000
Switched virtual interfaces (SVIs): 1000
Jumbo frame size: 9216
IPv4 routes: 256000
Layer 3 multicast routes: 32000
Layer 2 multicast routes: 32000
QoS hardware entries: 16000
Packet buffer size: 108 MB
Features
Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, LLDP support, Energy Efficient Ethernet, Management Information Base (MIB), Virtual Routing and Forwarding (VRF), Flexible NetFlow (FNF), 802.1x authentication, DiffServ Code Point (DSCP) support, Location ID Separation Protocol (LISP), CoAP support, secure boot
Encryption Algorithm
128-bit AES, 256-bit AES
Compliant Standards
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ae, IEEE 802.1ab (LLDP), IEEE 802.3bt
Expansion / Connectivity
Interfaces
1 x console - RJ-45
1 x 1000Base-T (management) - RJ-45
1 x USB 3.0 - Type A
1 x management (mini-USB) - Type B
4 x 10Gb Ethernet (uplink) - SFP+
4 x 40Gb Ethernet/100Gb Ethernet - QSFP
Miscellaneous
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, EN 300 386 V1.6.1, EN 55022 Class A, EN 300 386, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317
Power
Power Consumption Operational
650 Watt
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
10 - 95% (non-condensing)
Compatibility Information
Designed For
P/N: C9404R, C9404R=, C9404R-10A, C9404R-1A, C9404R-48U-BDL-EDU, C9404R-48U-BNDL-1A, C9404R-48U-BNDL-1E, C9404R-48U-BNDL-A, C9404R-48UBNDLA-RF, C9404R-48U-BNDL-E, C9404R-RF, C9404R-WS, C9407R, C9407R=, C9407R-10A, C9407R-1A, C9407R-1A-DUP, C9407R-96U-BDL-EDU, C9407R-96U-BNDL-1A, C9407R-96U-BNDL-1E, C9407R-96U-BNDL-A, C9407R-96UBNDLA-RF, C9407R-96UBNDLA-WS, C9407R-96U-BNDL-E, C9407R96U-BUN-A-DU, C9407R-96U-STK-EDU, C9407R-CONF1, C9407R-P, C9407R-RF, C9407R-WS, C9410R, C9410R=, C9410R-1A, C9410R-96U-BDL-EDU, C9410R-96U-BNDL-1A, C9410R-96U-BNDL-1E, C9410R-96U-BNDL-A, C9410R-96UBNDLA-RF, C9410R-96UBNDLA-WS, C9410R-96U-BNDL-E, C9410R-96U-BUNDL-A, C9410R-P, C9410R-RF, C9410R-WS
