General
Device Type
Switch - 48 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable 1U
Ports
48 x 10/100/1000 (PoE+) + 4 x 1/10 Gigabit (uplink)
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 176 Gbps ¦ Forwarding rate: 130.95 Mpps ¦ Forwarding rate with stacking: 369.05 Mpps ¦ Stacking bandwidth: 496 Gbps
Capacity
Priority queues: 8 ¦ Maximum number of VLANs: 4094 ¦ Active VLANs: 1000 ¦ Link aggregation ports: 8
MAC Address Table Size
32000 entries
Routing Protocol
VRRP, OSPFv2, static IP routing, STP
Remote Management Protocol
SNMP, DHCP, Syslog
Authentication Method
RADIUS
Features
VLAN support, IGMP snooping, port mirroring, Broadcast Storm Control, firmware upgradable, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), Uni-Directional Link Detection (UDLD), DHCP relay, Port Security, Multicast filtering function, 802.1x authentication, 3 fans, Role-Based Access Control (RBAC), push notification, Root Guard, Loop Guard, Zero-touch provisioning (ZTP), MAC Access Bypass (MAB), BPDU Guard, VLAN trunking, Cisco Discovery Protocol (CDP), Multicast routing, DSCP to CoS mapping
Compliant Standards
IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Expansion / Connectivity
Interfaces
48 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 4 x 1/10GBase-X SFP+ uplink ¦ 2 x network stack device ¦ 1 x management
Power
Power Device
Internal power supply - hot-plug
Power Consumption Stand by
67.4 Watt
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CNS 13438, EN 300 386 V1.6.1, EN 55022 Class A, KN32, KN35, EN 55032, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, TCVN 7317, V-2/2015.04, V-3/2015.04, FCC CFR 47 Part 15 Class A, VCCI-CISPR 32 Class A
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 90%
