General
Device Type
Radio access point
Networking
Connectivity Technology
Wireless
Data Transfer Rate
4.8 Gbps
Line Coding Format
256 QAM, OFDM, 1024 QAM, OFDMA, DSSS
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6)
Frequency Band
2.4 GHz, 5 GHz
Features
Trusted Platform Module (TPM), packet aggregation A-MPDU, packet aggregation A-MSDU, SU-MIMO technology, Tri-Band, Orthogonal Frequency Division Multiplexing (OFDM), 2x2 MIMO technology, security slot (Kensington security lock compatible), Bluetooth (BLE) clients support, 4x4 MIMO technology, Transmit Beamforming
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.15.4, IEEE 802.11ac Wave 2, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Aerial
Internet of Things (IoT)
Communications Technology
Bluetooth Low Energy (LE), Zigbee
Expansion / Connectivity
Interfaces
1 x 2.5 GBase-T (PoE) - RJ-45
1 x 1000Base-T - RJ-45
1 x USB 2.0 - Type A
Miscellaneous
Included Accessories
Mounting kit
Compliant Standards
EN 61000-3-2, EN 61000-3-3, EN55024, IEC 60601-1-2, ICES-003 Class B, AS/NZS 60950-1, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03, AS/NZS 4268, EN 60601-1-2, FCC CFR47 Part 15 B, EN 62311, EN 50581, EN 300.440, EN 300 328, RoHS 2011/65/EU, EN 50385, EN 55011 class B, EN 301 489-1, RSS-247, EN 62479, EN 55032 Class B, EN 301 893, CISPR 32, FCC Subpart C 15.247, FCC Subpart E 15.407, EN 301 489-3, EN 301 489-17
Power
Power Over Ethernet (PoE) Supported
PoE
Power Consumption Operational
23.74 Watt
Manufacturer Warranty
Service & Support
Limited warranty - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 95% (non-condensing)
