Extreme Networks ExtremeWireless AP305C

Radio access point

Indoor

13.3 cm

13.3 cm

3.7 cm

400 g

EMEA, Rest of World

External

Wireless

256 QAM, OFDM, 1024 QAM, DSSS

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6)

OFDM, DSSS

2.4 GHz, 5 GHz

Maximum data rate (2.4 GHz): 1200 Mbps ¦ Maximum data rate (5 GHz): 574 Mbps

SSIDs per radio: 8 ¦ SSIDs total: 16 ¦ Users per radio: 512 ¦ Total users: 1024

Auto-sensing per device, Wi-Fi Multimedia (WMM) support, Direct Sequence Spread Spectrum (DSSS), packet aggregation A-MPDU, packet aggregation A-MSDU, dual band, 2x2:2 MU-MIMO technology, 8KV ESD Protector (contact discharge), 15KV ESD Protector (air-gap discharge), security slot (Kensington security lock compatible), Cellular Coexistence Filter (CCF), Transmit Beamforming, Private Pre-Shared Key (PPSK)

WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, WPA3-Personal, WPA2-Personal, WPA-Personal

IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac Wave 2, IEEE 802.11ac Wave 1, IEEE 802.11ax, Wi-Fi CERTIFIED 6

Internal

4

Omni-directional

1 x 1000Base-T (PoE) - RJ-45 ¦ 1 x USB 2.0 - Type A

EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class B, AS/NZS 60950-1, UL 2043, RoHS, IEC 60950-1, EN 60950-1, AS/NZS 4268, EN 60601-1-2, FCC CFR47 Part 15 B, EN 62311, Directive 2011/65/EU, EN 50581, EN 300.440, EN 300 328, EN 50385, EN 301 489-1, RSS-247, EN 55032 Class B, EN 301 893, CISPR 32, FCC Subpart C 15.247, FCC Subpart E 15.407, EN 301 489-17, IEC 62368, EN 62368, AS/NZS 62368, IEC/EN 60601-1-2, EN 55011 Group 1 Class B

PoE

9.98 Watt

Limited warranty - lifetime

0 °C

40 °C

10 - 95% (non-condensing)
