General
Device Type
Console server
Built-in Devices
Temperature sensor
Localisation
United States
Processor / Memory / Storage
Processors Installed
1 x ARM A9 766 MHz
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232, RS-422, RS-485
Remote Management Protocol
SNMP, Telnet, HTTP, HTTPS, TFTP, SSH, CLI
Features
Auto-sensing per device, Syslog support, packet filtering, IPv6 support, IP address filtering, IPSec NAT-Traversal (NAT-T), IPv4 support, SNMP trap, failover protection, Zero-touch provisioning (ZTP), One-Time Password (OTP), IP forwarding support, break-over SSH support, 4G USB Dongle Support
Authentication Method
Kerberos, SecurID, Secure Shell (SSH), RADIUS, PAP, CHAP, X.509 certificates, TACACS+, Secure Shell v.2 (SSH2), LDAP, Active Directory, Extensible Authentication Protocol (EAP)
Communications
Supported Flash Memory Cards
SD Memory Card
Expansion / Connectivity
Interfaces
2 x 1000Base-X - SFP (mini-GBIC)
2 x 1000Base-T - RJ-45
1 x management (RS-232) - RJ-45
2 x RS-232/422/485 - RJ-45
46 x RS-232 - RJ-45
8 x USB 2.0 - Type A
1 x sensor - RJ-45
1 x digital input - RJ-45
Miscellaneous
Compliant Standards
FCC Class A certified, UL, VCCI, cUL, EN 60950, ICES-003, CB, KCC, RCM, CU
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
6.2 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
-10 °C
Max Operating Temperature
60 °C
Humidity Range Operating
20 - 80% (non-condensing)
