NVIDIA Spectrum SN2100 - Switch

Productcode: 920-9N100-00F7-0C0 | EAN/UPC: 8592978384098

€ 12.917,87 excl.btw

NVIDIA Spectrum SN2100 - Switch - L3 - Managed - 16 x 100 Gigabit QSFP28 - back to front airflow - rack-mountable

16 QSFP28 ports for high-density network configurations
Layer 3 advanced switching for efficient routing and segmentation
Dual internal power supply for continuous operation
Low latency of 300 µs for fast data transmission
Rack-mountable design fits seamlessly into existing data center infrastructure

Op voorraad: 0 stuk(s)

Levertijd:

Product:
NVIDIA Spectrum SN2100 - Switch

€ 15630,62 incl. 21% btw € 12917,87excl. 21% btw

Winkelwagen Offerte

Stuur mij een notificatie bij voorraad

Omschrijving

NVIDIA Spectrum SN2100 - Switch - L3 - Managed - 16 x 100 Gigabit QSFP28 - back to front airflow - rack-mountable

Product features

Efficient management
Equipped with a Gigabit Ethernet management port, the NVIDIA Spectrum SN2100 ensures seamless network management and monitoring capabilities, making it a suitable choice for sophisticated network environments.
High-density connectivity
With 16 QSFP28 ports, the NVIDIA Spectrum SN2100 offers high-density connectivity options, supporting up to 16 connections, which facilitates scalable network architectures and efficient data center operations.
Robust power supply
The dual internal power supply design ensures continuous operation and redundancy, ensuring that your network remains operational even in the event of a power supply failure.
Advanced Layer 3 switching
Layer 3 advanced switching capabilities provide efficient routing and segmentation, enhancing the performance and security of enterprise networks.
Low latency performance
Designed to deliver exceptional performance, the NVIDIA Spectrum SN2100 boasts a low latency of 300 µs, ensuring fast data transmission and reducing delay in critical network applications.

Specificaties

General

Device Type

Switch - 16 ports - L3 - Managed

Enclosure Type

Back to front airflow rack-mountable 1U

Subtype

100 Gigabit Ethernet

Ports

16 x 100 Gigabit QSFP28

Performance

Throughput: 1.6 Tbps ¦ Latency: 300 µs ¦ Packets per second: 2.38 Bpps

Capacity

Packet buffer size: 16 MB

RAM

8 GB

Flash Memory

16 GB

Expansion / Connectivity

Interfaces

16 x 100Gbit LAN QSFP28 ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x serial RJ-45 ¦ 1 x mini-USB

Power

Power Device

Internal power supply

Installed Qty

Max Supported Qty

Voltage Required

AC 100-264 V (50 - 60 Hz)

Power Consumption Operational

94 Watt

Miscellaneous

Compliant Standards

VCCI, CB, FCC, RoHS, ICES, cTUVus, RCM, CU

Software / System Requirements

Software Included

Cumulus Linux

Dimensions & Weight

Width

20 cm

Depth

50.8 cm

Height

4.39 cm

Weight

4.54 kg

Manufacturer Warranty

Service & Support

Limited warranty - 1 year

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

5 - 85%

Min Storage Temperature

-40 °C

Max Storage Temperature

70 °C

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
