General
Device Type
Wi-Fi system - mesh - 2-port switch (integrated)
Wi-Fi System Components
Router
Wi-Fi System Coverage
Up to 2,400 sq.ft
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Frequency Band
2.4 GHz / 5 GHz
Network / Transport Protocol
PPTP, L2TP, PPPoE, DHCP, DDNS
Encryption Algorithm
WPA, WPA2, WPA-Enterprise, WPS, WPA3-Personal
Features
NAT support, WOL, parental control, MIMO technology, QoS, SSH support, port forwarding, reset button, port triggering, ASUSWRT, system log, ASUS Router App, router mode, flexible UFT, DMZ support, traffic monitoring, ASUS AiMesh, ASUS AiProtection Classic, Bandwidth Limiter, OpenVPN client, PPTP VPN client, OpenVPN server, IPTV support, WPS button, 160MHz bandwidth support, Guest Network, IGMP support, AiMesh node mode, Let's Encrypt, Bandwidth Monitor, DDNS, L2TP VPN client, IPSec VPN server, PPTP VPN server, malicious site blocking
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, REACH, FCC Part 15 Class B
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Intelligent Assistant
Alexa
Expansion / Connectivity
Interfaces
WAN / LAN: 1 x 1000Base-T - RJ-45
LAN: 1 x 1000Base-T - RJ-45
Aerial
Power
Power Device
External power adapter
Voltage Required
AC 110-240 V
Miscellaneous
Cables Included
1 x network cable
Dimensions & Weight
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
50 - 90%
