General
Device Type
Switch - 40 ports
Enclosure Type
Front to back airflow rack-mountable 1U
Subtype
100 Gigabit Ethernet
Ports
40 x 100 Gigabit QSFP28 / 40 Gigabit QSFP28
Performance
Switching capacity: 4 Tbps
Forwarding capacity: 2000 Mpps
Capacity
25G ports (with QSFP28 breakout): 72
Packet buffer size: 8 GB
MAC addresses (default profile): 600000
MAC addresses (route profile): 190000
VLANs supported: 4096
IPv4 ACL entries: 4000
IPv6 ACL entries: 2000
L2 ACL entries: 2000
Maximum members in a standard LAG: 64
Maximum number of MCT switches: 2
Bridge domains: 4000
QoS priority queues per port: 8
Jumbo Frame Support
9216 bytes
Routing Protocol
OSPF, IS-IS, BGP, MPLS
Remote Management Protocol
SNMP, CLI, NETCONF, YANG
Features
Flow control, auto-negotiation, RSTP support, MSTP support, ACL support, VPLS, VXLAN, Link Aggregation, EVPN, CFM, 5+1 redundant fans, secure boot, IPv4 and IPv6 dual stack, DDoS Protection, integrated BMC, measured boot
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3bj
Processor
1 x Intel Atom C3758: 2.2 GHz
Built-in Devices
128 GB SSD, 6 x fans
Status Indicators
Power, system, link/activity, fan, fault, PSU, speed, secure
Expansion / Connectivity
Interfaces
40 x 40/100Gbit LAN QSFP28
1 x 1000Base-T RJ-45 management
1 x serial (console) RJ-45
1 x USB Type A
Power
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
DC ±39 - ±72 V
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
BSMI, EN 61000-3-2, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, EN 61000-3-3, EN55024, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, EMC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, EN 60950-1, KCC, EN 55011, ANATEL, VCCI Class A, EAC, CNS 13438, RoHS 2011/65/EU, WEEE 2012/19/EU, FCC CFR47 Part 15 A, LVD 2014/35/EU, EN 300 386, GB 4943.1-2011, ITU Y.1731, CNS 14336-1, EN 62368-1, IEC 62368-1, IEC/EN 61000-4-11, EN 55032 Class A, ETS 300 132-2, ETS 300 253, NRCS, ACMA RCM, CISPR 32 Class A, ITU-T G.8032, EN 60825-1 Class 1, UL 62368-1, CAN/CSA-C22.2 No. 60950-1-01, China RoHS SJ/T 11364-2014, AS/NZS CISPR 32, GB/T9254-2008, IEC 60950-1 (CB Certificate and CB Test Report), CAN/CSA-C22.2 No. 62368-1-14, CNS 15663, Mexico NOM, RoHS 2015/863/EU, EMCD 2014/30/EU, CISPR 24 Class A, EU REACH, ITU-T G.8013
Software / System Requirements
Software Included
Extreme SLX-OS
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
