Extreme Networks 5420F - Switch

Switch - 24 ports - L3 - stackable

Rack-mountable

Gigabit Ethernet

24 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink)

PoE

380 W

Switching capacity: 208 Gbps
Forwarding rate: 154.8 Mpps

ARP table (IPv4): 16000
IPv4 routes: 12000
IP multicast entries: 6000
ARP table (IPv6): 6000
IPv6 neighbour table entries: 6000
ACL entries (ingress): 8000
ACL entries (egress): 1024
Maximum number of VLANs: 4094
IP interfaces: 1533
Policy profiles: 63
Unique permit/deny rules per switch: 4024
ARP table (IPv4): 8000
IPv4 routes: 11750
IP multicast entries: 4000
ARP table (IPv6): 5750
IPv6 neighbour table entries: 8000
ACL entries (ingress): 1024
ACL entries (egress): 336
Maximum number of VLANs: 4059
IP interfaces: 248

Mode button, fan module

IEEE 802.3at, IEEE 802.3bt

24 x 1000Base-T RJ-45 30 W
4 x 10GBase-X SFP+ uplink
2 x network stack device SFP-DD unpopulated
1 x management (Gigabit LAN) RJ-45
1 x 10/100/1000 Base-T RJ-45 out-of-band network management
2 x USB Type A management
1 x console (micro-USB)

Internal power supply

1

2

Optional

660 Watt

AC

Included

Base Software License

44.2 cm

28.7 cm

4.32 cm

4.6 kg

Limited warranty - lifetime
