General
Device Type
Router - 5-port switch (integrated)
Enclosure Type
DIN rail mountable - modular
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
PPTP, NTP, ICMP/IP, IPSec, ARP, FTP, DHCP, DNS, DDNS, IPv4, IPv6, FTPS, UDP, TCP
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, EIGRP, NHRP, static IP routing, GRE, RIPng, RSTP
Remote Management Protocol
SNMP, Telnet, HTTP, HTTPS, SSH
Encryption Algorithm
DES, RC2, MD5, CAST5, MPPE, TLS, DH, SHA-1, 128-bit AES, 256-bit AES, AES-CBC, IKEv2, AES-GCM, CRL, 128-bit Blowfish, IKEv1, SHA-512, SHA-224, Chacha20-Poly 1305, IDEA-128, DESX
Authentication Method
RADIUS, PAP, CHAP, X.509 certificates, MS-CHAP, MS-CHAP v.2
Features
SNAT support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, MAC address filtering, IP address filtering, half duplex mode, full duplex mode, Dead Peer Detection (DPD), Dynamic Multipoint VPN (DMVPN), DHCP server, DHCP relay, NTP server, SNMP trap, e-mail notification, Pre-Shared Key (PSK), Simple Certificate Enrollment Protocol (SCEP), DNAT support, RESTful APIs, PPTP client, PPTP server, OpenVPN client, OpenVPN server, signed firmware, SNMP agent, Lua script
Compliant Standards
IEEE 802.1Q, EN 61000-6-2, EN 61000-6-3, EN 61131-2, IP40, FCC Part 15 Class B, EN 60068-2-1, EN 55032 Class B, EN 60068-2-27, EN 60068-2-6, EN 55035, EN 60068-2-14, IEC 61709, IEC 62368, EN 62368, EN 60068-2-2, UKCA, EN 60068-2-30, SN 29500
Status Indicators
Power, WAN, SFP
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Platform
Cumulocity, Thingsboard, AnyViz, Azure IoT Hub, Bosch IoT Suite, AWS IoT Core
Expansion / Connectivity
Interfaces
5 x 10Base-T/100Base-TX - RJ-45 ¦ 2 x DI ¦ 2 x 100Base-X/1000Base-X - SFP (mini-GBIC)
Power
Voltage Required
DC 12 - 24 V
Miscellaneous
Dimensions & Weight
Environmental Parameters
Humidity Range Operating
0 - 95% (non-condensing)
