General
Product Type
Motherboard - ATX
Processor Socket
Socket AM5
Compatible Processors
Ryzen (supports Ryzen 7000 Series)
Supported RAM
Bus Clock
4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz (O.C.), 5600 MHz (O.C.), 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.)
Supported RAM Integrity Check
Non-ECC, on-die ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture, AMD EXPO technology
Audio
Compliant Standards
High Definition Audio
LAN
Network Interfaces
2.5 Gigabit Ethernet
Expansion / Connectivity
Expansion Slots
1 x CPU
4 x DIMM 288-pin
1 x PCIe 4.0 x16
2 x PCIe 4.0 x16 (x4 mode)
1 x PCIe 3.0 x1
2 x M.2 socket (2242/2260/2280 M.2 Key M slot)
1 x M.2 socket (2242/2260/2280/22110 M.2 Key M slot)
1 x M.2 socket (Key E)
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10
PCIe 4.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 / RAID 10
PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10
Interfaces
1 x HDMI
1 x DisplayPort
1 x USB-C 3.2 Gen2x2
3 x USB 3.2 Gen 2
4 x USB 3.2 Gen 1
2 x USB 2.0
1 x LAN (2.5Gigabit Ethernet)
1 x audio line-in - mini-jack
1 x microphone - mini-jack
1 x audio line-out - mini-jack
PS/2 keyboard / mouse
Internal Interfaces
1 x USB-C 3.2 Gen 1 - header
4 x USB 3.2 Gen 1 - header
4 x USB 2.0 - header
1 x serial - header
1 x audio - header
1 x SPDIF out - header
1 x SPI - header
1 x Thunderbolt - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector, 4-pin ATX12V connector
Features
BIOS Features
UEFI BIOS, ASUS EZ Flash 3
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
Hardware Features
ASUS OptiMem II, BIOS FlashBack button, jack retasking, audio jack detect technology, Clear CMOS Button, ASUS 5X Protection III, ASUS DIGI+ VRM, ESD Guards, LANGuard, overvoltage protection, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, ASUS Q-Design, M.2 Q-Latch, Q-DIMM, Q-LED Core, Q-Slot, M.2 heatsink, VRM heatsink design, ASUS EZ DIY, BIOS FlashBack LED, ASUS ProCool, ASUS Aura Sync, ASUS TurboV EVO, CrashFree BIOS 3, 12+2 DrMOS power stages, 60A Power Stage, Water Pump Header, 6 Layer PCB, DIY Friendly Design, Stack Cool 3+
Miscellaneous
Included Accessories
IO shield, 1 x M.2 rubber package, 2 x M.2 screw package
Cables Included
2 x Serial ATA cable
Software Included
Armoury Crate, ASUS AURA Creator, ASUS Fan Xpert 4, ASUS AI Suite III, PC Cleaner, ASUS CPU-Z, Norton AntiVirus (Trial), WinRAR
Compliant Standards
DisplayPort 1.4, FCC Part 15 Class B, VCCI Class B ITE, JATE, KC, EU REACH, EU RoHS, UKCA, WEEE
