General
Product Type
Motherboard - micro ATX
Processor Socket
Socket AM4
Compatible Processors
(supports Ryzen 3000 Series/ 3000 G-Series/ 4000 Series/ 4000 G-Series/ 5000 Series/ 5000 G-Series)
Supported RAM
Bus Clock
1600 MHz, 1467 MHz, 1334 MHz, 1200 MHz, 1067 MHz, 2367 MHz (O.C.)
Supported RAM Integrity Check
Non-ECC, ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Audio
Audio Codec
Realtek ALC1200
Compliant Standards
High Definition Audio
LAN
Network Interfaces
Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.3
Expansion / Connectivity
Expansion Slots
1 x CPU
4 x DIMM 288-pin
1 x PCIe 4.0 x16
1 x PCIe 3.0 x16 (x4 mode)
1 x PCIe 3.0 x1
2 x M.2 socket (2280 M.2 Key M slot)
Storage Interfaces
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10
SATA-600 / PCIe 3.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10
SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10
Interfaces
1 x HDMI
1 x DisplayPort
2 x USB 2.0
1 x PS/2 keyboard / mouse
4 x USB 3.2 Gen 1
1 x LAN (Gigabit Ethernet)
2 x aerial
1 x microphone - mini-jack
1 x audio line-in - mini-jack
1 x audio line-out - mini-jack
Internal Interfaces
2 x USB 2.0 - header
2 x USB 3.2 Gen 1 - header
1 x USB-C 3.2 Gen 1 - header
1 x audio - header
1 x SPI - header
1 x serial - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Features
WfM 2.0 support, SMBIOS 2.7 support, DMI 2.7 support, ACPI 5.0 support, UEFI BIOS, PnP 1.0a support
Hardware Monitoring
Fan fail warning, fan control, system voltage, temperature detection, water cooling flow rate, fan speed detection
Hardware Features
Q-Flash, Q-Flash Plus, RGB FUSION, Q-Flash Plus button, Ultra Durable, DIY Friendly Design, 5+3 Phase Power Design, chipset heatsink, GIGABYTE Smart Fan 6, PCIe EZ Latch, VRM heatsink design, WIFI EZ Plug
Miscellaneous
Included Accessories
IO shield, Wi-Fi aerial
Cables Included
1 x Serial ATA cable
Software Included
Norton Internet Security (OEM Version), LAN manager, GIGABYTE App Center, GIGABYTE Control Center
Compliant Standards
HDCP 2.3, DisplayPort 1.4
