General
Product Type
Motherboard - ATX
Processor Socket
Socket AM5
Compatible Processors
Ryzen (supports Ryzen 7000/8000/9000 Series)
Supported RAM
Supported RAM Integrity Check
Non-ECC, on-die ECC
Registered or Buffered
Unbuffered
Features
AMD EXPO technology, dual channel memory architecture
Audio
Audio Codec
Realtek ALC4080
Compliant Standards
High Definition Audio, DTS Sound Unbound
LAN
Network Controller
Intel I225-V
Network Interfaces
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4
Expansion / Connectivity
Expansion Slots
1 x CPU
4 x DIMM 288-pin
1 x PCIe 5.0 x16
1 x PCIe 4.0 x16 (x4 mode)
1 x M.2 socket (2280/22110 M.2 Key M slot)
1 x M.2 socket (2242/2260/2280 M.2 Key M slot)
2 x M.2 socket (2280 M.2 Key M slot)
Storage Interfaces
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10
PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10
PCIe 4.0 -connectors: 3 x M.2 - RAID 0 / RAID 1 / RAID 10
Interfaces
1 x HDMI
1 x DisplayPort
1 x USB-C 3.2 Gen2x2
2 x USB 3.2 Gen 2
4 x USB 3.2 Gen 1
2 x USB 2.0
1 x LAN (2.5Gigabit Ethernet)
1 x USB-C 3.2 Gen 2
1 x SPDIF out
1 x microphone - mini-jack
1 x audio line-out - mini-jack
2 x aerial
Internal Interfaces
4 x USB 2.0 - header
2 x USB 3.2 Gen 1 - header
1 x USB-C 3.2 Gen 2 - header
1 x audio - header
1 x Thunderbolt - header
Power Connectors
24-pin main power connector, 2 x 8-pin ATX12V connectors
Features
BIOS Features
UEFI BIOS, ASUS EZ Flash 3
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
Hardware Features
ASUS OptiMem II, SupremeFX Shielding technology, Savitech SV3H712 amplifier, BIOS FlashBack button, Water Pump Header, jack retasking, audio jack detect technology, ASUS Extreme Engine Digi+, 5K Black Metallic Capacitors, ASUS Q-Design, M.2 Q-Latch, PCIe Slot Q-Release, Q-LED, Q-DIMM, Q-Slot, M.2 heatsink, VRM heatsink design, ASUS EZ DIY, BIOS FlashBack LED, ASUS ProCool, pre-mounted I/O shield, ASUS SafeSlot, ASUS SafeDIMM, ASUS Aura Sync, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, CrashFree BIOS 3, 14+2+2 Phase Power Design, 80A Power Stage, DIY Friendly Design, ASUS Enhanced Memory Profile (AEMP)
Miscellaneous
Included Accessories
Thermal pad for M.2 SSD, ASUS Wi-Fi Q-antenna, cable ties, M.2 Q-Latch, ROG key chain, STRIX stickers, ROG thank you card, 4 x M.2 rubber package
Cables Included
2 x Serial ATA cable
Software Included
ROG GameFirst VI, ROG CPU-Z, Sonic Radar III, Sonic Studio III, Armoury Crate, AIDA64 Extreme (60 days trial), ASUS AURA Creator, ASUS Fan Xpert 4, ASUS AI Suite III, ASUS Turbo App, PC Cleaner, MyAsus, WinRAR, ASUS DriverHub, HWiNFO, WinRAR (40 days trial), Norton 360 for Gamers (60 days trial), Adobe Creative Cloud (free trial)
Compliant Standards
FCC Part 15 Class B, VCCI Class B ITE, JATE, EU REACH, EU RoHS, UKCA, DisplayPort 1.4
