General
Product Type
Motherboard - ATX
Processor Socket
Socket AM4
Compatible Processors
Ryzen (supports 3rd Generation Ryzen)
Supported RAM
Bus Clock
2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 3200 MHz
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture
Audio
Audio Codec
SupremeFX (S1220A)
Compliant Standards
High Definition Audio, DTS Sound Unbound
LAN
Network Controller
Intel I255-V
Network Interfaces
2.5 Gigabit Ethernet
Expansion / Connectivity
Expansion Slots
1 x CPU
4 x DIMM 288-pin
1 x PCIe 4.0 x16
1 x PCIe 3.0 x16 (x4 mode)
3 x PCIe 3.0 x1
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10
SATA-600 / PCIe 3.0 -connectors: 2 x M.2
Interfaces
1 x LAN (2.5Gigabit Ethernet)
4 x USB 3.2 Gen 1
1 x audio line-in - mini-jack
1 x audio line-out - mini-jack
1 x microphone - mini-jack
1 x USB-C Gen2
1 x USB 3.2 Gen 2
1 x TOSLINK
1 x audio line-out (center/subwoofer) - mini-jack
1 x audio line-out (rear) - mini-jack
2 x USB 2.0
1 x DisplayPort
1 x HDMI
Internal Interfaces
4 x USB 2.0 - header
2 x USB 3.2 Gen 1 - header
1 x Thunderbolt - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Features
BIOS FlashBack, UEFI BIOS
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
Hardware Features
Jack retasking, ASUS Q-Design, ASUS TurboV EVO, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, CrashFree BIOS 3, audio jack detect technology, ASUS EPU (Energy Processing Unit), ASUS DIGI+ VRM, SupremeFX Shielding technology, AMD CrossFireX technology support, Gold Plated Audio Hardware, Preboot eXecution Environment (PXE), LANGuard, ASUS Fan Xpert 4, ASUS SafeSlot, Sonic Radar III, Sonic Studio III, ASUS ProCool, pre-mounted I/O shield, ASUS Aura Sync, ASUS OptiMem II, Armoury Crate, GameFirst VI
Miscellaneous
Included Accessories
Cable ties, 1 x M.2 screw, ROG fan stickers, ROG thank you card, RGB Addressable LED extension cable, rubber pad
Cables Included
4 x Serial ATA cable
Software Included
ROG CPU-Z, ASUS AI Suite III, ASUS EZ Update, Overwolf, ASUS EZ Flash 3, Antivirus, WinRAR, ASUS ROG RAMCache III, Sonic Studio Virtual Mixer
Compliant Standards
DisplayPort 1.2
