General
Product Type
Motherboard - ATX
Processor Socket
Socket AM4
Compatible Processors
Ryzen (supports 2nd and 3rd Generation Ryzen / 1st and 2nd Generation Ryzen with Radeon Vega Graphics)
Supported RAM
Bus Clock
2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3400 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.), 4800 MHz (O.C.), 3200 MHz
Supported RAM Integrity Check
ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture
Audio
Compliant Standards
High Definition Audio, DTS Sound Unbound
LAN
Network Controller
Intel I211-AT / Realtek RTL8125-CG
Network Interfaces
Gigabit Ethernet, 2.5 Gigabit Ethernet
Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 4.0 x16 (dual x8 mode; single card: x16 mode) ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 4.0 x1
Storage Interfaces
SATA-600 -connectors: 8 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 4.0 -connectors: 2 x M.2
Interfaces
1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x TOSLINK ¦ 4 x USB 3.2 Gen 1 ¦ 7 x USB 3.2 Gen 2 ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x USB-C Gen2
Internal Interfaces
4 x USB 2.0 - header ¦ 1 x USB 3.2 Gen 2 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 1 x speaker - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Features
WfM 2.0 support, BIOS FlashBack, UEFI BIOS, ASUS EZ Flash 3, SMBIOS 3.2 support, ACPI 6.2 support
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
C.P.R. (CPU Parameter Recall), ASUS Q-Design, GameFirst, Q-DIMM, Q-LED, Q-Slot, CrashFree BIOS 3, ASUS Q-Connector, ASUS Extreme Tweaker, NVIDIA 2-way SLI Technology Support, ASUS DIGI+ VRM, ASUS ROG Extreme OC, Q-Code, SupremeFX Shielding technology, AMD CrossFireX technology support, AMD 3-way CrossFireX technology support, Preboot eXecution Environment (PXE), Clear CMOS Button, Dual Intelligent Processors 5, LANGuard, ASUS Fan Xpert 4, ASUS SafeSlot, Sonic Radar III, Sonic Studio III, M.2 heatsink, pre-mounted I/O shield, AMD StoreMI technology, ASUS Aura Sync, Armoury Crate, ESS ES9023P, ASUS Node, MicroFine Alloy Chokes, PowIRstage IR3555 MOSFETs, 10K Black Metallic Capacitors, ASUS OptiMem III
Miscellaneous
Included Accessories
1 x M.2 screw, ROG coasters, RGB (RGBW) LED strip extension cable, ROG big sticker, ROG thank you card, RGB Addressable LED extension cable, Q-Connector
Cables Included
4 x Serial ATA cable
Software Included
Drivers & Utilities, ASUS AI Charger, ROG CPU-Z, ASUS AI Suite III, RAMdisk, ASUS Turbo App, ASUS ROG RAMCache III, ROG GameFirst V, Sonic Studio Virtual Mixer
