General
Printer Fonts
Scalable PCL x 73
Bitmapped PCL x 12
Scalable PostScript x 66
Device Type
Multifunction printer
Printing Technology
LED - colour
Recommended Monthly Volume
Up to 3000 pages
Display Colour Support
Colour
Display Features
Touch screen
Connection Availability
Yes
Interface
USB 2.0, Wi-Fi(n), Gigabit LAN
Office Machine Features
Scan to e-mail, scan to OCR, scan to image, scan to folder, scan to network folder, scan to FTP, scan to SharePoint, scan to SMB, N-Up printing, scan to PDF, scan to Secure PDF
Memory
Copying
Max Copying Speed
Up to 26 ppm (mono) / up to 26 ppm (colour)
Max Copying Resolution
Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (colour)
Max Copying Resolution Class
Up to 600 x 600 dpi (mono) / up to 600 x 600 dpi (colour)
Max Document Enlargement
400%
Max Document Reduction
25%
Copying Features
ID Copy, Sort, N-in-1
Printing
Max Printing Resolution
Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (colour)
Max Printing Resolution Class
Up to 600 x 2400 dpi (mono) / up to 600 x 2400 dpi (colour)
Max Printing Speed
Up to 26 ppm (mono) / up to 26 ppm (colour)
Printer Drivers / Emulations
PCL 5e, PCL 5c, PCL 6 (XL 3.0), BR-Script 3, PDF 1.7
First Print Out Time B/W
13.5 sec
First Print Out Time Colour
13.5 sec
Scanning
Optical Resolution
1200 x 1200 dpi
Interpolated Resolution
19200 x 19200 dpi
Colour Depth (Internal)
48-bit
Document & Media Handling
Document Feeder Capacity
50 sheets
Min Media Size
105 x 147.3 mm
Supported Media Type
Plain paper, thin paper, thick paper, recycled paper, bond paper, labels, envelopes, glossy paper
Supported Media Sizes
ANSI A (Letter) (216 x 279 mm), Legal (216 x 356 mm), Executive (184 x 267 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), A6 (105 x 148 mm), JIS B5 (182 x 257 mm), B5 (176 x 250 mm), JIS B6 (128 x 182 mm), Folio (203 x 330 mm), 195 x 270 mm, 76.2 x 116 mm
Supported Envelope Sizes
International DL (110 x 220 mm), Com-10 (105 x 241 mm), International C5 (162 x 229 mm), Monarch (98.4 x 190.5 mm)
Standard Media Capacity
250 sheets
Bypass Feeder Capacity
1 sheet
Output Trays Capacity
150 sheets
Document & Media Handling Details
Input tray - 250 sheets - Legal (216 x 356 mm) weight: 60 g/m² - 163 g/m²
Bypass tray - 1 sheet size: 76.2 x 116 mm - 216 x 355.6 mm weight: 60 g/m² - 163 g/m²
Output tray - 150 sheets
ADF - 50 sheets size: 105 x 147.3 mm - 215.9 x 355.6 mm weight: 60 g/m² - 105 g/m²
Speed Details
Printing: up to 26 ppm (A4) - B/W
Printing: up to 26 ppm (A4) - colour
Copying: up to 26 ppm (A4) - B/W
Copying: up to 26 ppm (A4) - colour
Scanning: up to 27 ppm (A4) - B/W (ISO/IEC 17991)
Scanning: up to 21 ipm (A4) - colour (ISO/IEC 17991)
Printing: up to 10 spm (A4) - B/W duplex
Printing: up to 10 spm (A4) - colour duplex
Connections
Interfaces
1 x USB 2.0
1 x Gigabit LAN
Security Protocols & Features
802.1x, active directory, LDAP, automatic intrusion detection, digitally-signed firmware, IP filtering, EAP-MD5, restrict network protocols, secure function lock v3, Secure Print, setting lock, syslog reporting, store print log, Wi-Fi Direct, WEP, WPA-PSK, TKIP, AES, WPA2-PSK, port-based network access control, APOP, SMTP, SSL, TLS, POP3, SNMP 3, EAP-FAST, PEAP, WPA3-SAE, EAP-TTLS, Kerberos, IPsec
Operating System Support
Windows 11, Linux, Apple Mac OS, Chrome OS
Power
Voltage Required
AC 220-240 V (50/60Hz)
Power Consumption Operational
560 Watt
Power Consumption Standby
70 Watt
Power Consumption Sleep
10 Watt
Miscellaneous
First Copy Out Time B/W
15.5 sec
First Copy Out Time Colour
15.5 sec
Consumables Included
1 x toner cartridge (black) - up to 1000 pages ISO/IEC 19798
1 x toner cartridge (cyan) - up to 1000 pages ISO/IEC 19798
1 x toner cartridge (magenta) - up to 1000 pages ISO/IEC 19798
1 x toner cartridge (yellow) - up to 1000 pages ISO/IEC 19798
1 x drum - up to 20000 pages 1 page per job - Brother DR248CL
1 x belt - up to 50000 pages 2 pages per job - Brother BU229CL
1 x waste toner collector - up to 50000 pages 5 pages per job
Environmental Standards
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
France: limited warranty - 2 years
Dimensions & Weight
Dimensions & Weight (Shipping)
Environmental Parameters
Sound Emission
47 dBA (operating)
Min Operating Temperature
10 °C
Max Operating Temperature
32.5 °C
Humidity Range Operating
20 - 80%
