General
Device Type
Multifunction printer
Printing Technology
LED - colour
Monthly Duty Cycle (max)
75000 pages
Recommended Monthly Volume
10000 pages
Display Colour Support
Colour
Display Features
Touch screen
Connection Availability
Yes
Interface
USB 2.0, Gigabit LAN, USB 2.0 host
Office Machine Features
Save to USB flash drive, scan to e-mail, save to network folder, scan to FTP
Memory
Max Supported Memory
1.25 GB
Copying
Max Copying Speed
Up to 35 ppm (mono) / up to 35 ppm (colour)
Max Copying Resolution
Up to 1200 x 1200 dpi (mono) / up to 1200 x 1200 dpi (colour)
Printing
Max Printing Resolution
Up to 1200 x 1200 dpi (mono) / up to 1200 x 1200 dpi (colour)
Max Printing Speed
Up to 35 ppm (mono) / up to 35 ppm (colour)
Printer Drivers / Emulations
PostScript 3, PCL 5c, IBM Proprinter, PCL 6 (XL), PDF 1.7, XPS, EPSON FX
First Print Out Time B/W
9.5 sec
First Print Out Time Colour
9.5 sec
Scanning
Optical Resolution
600 x 600 dpi
Fax Machine
Max Transmission Speed
33.6 Kbps
Data Compression System
MH, MR, MMR, JBIG
Total Memory Capacity
Up to 8192 pages
Fax Machine Features
One-Touch Dialing
40 station(s)
Speed Dialing
1000 station(s)
Broadcast Transmission
320 stations
Document & Media Handling
Min Original Size
105 x 148 mm
Max Original Size
A3/Ledger (297 x 432 mm)
Supported Original Sizes
ANSI A (Letter) (216 x 279 mm), Legal (216 x 356 mm), Executive (184 x 267 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), B5 (176 x 250 mm), A3 (297 x 420 mm), B4 (250 x 353 mm), A6 (105 x 148 mm), Folio (216 x 330 mm), Statement (139.7 x 215.9 mm), Tabloid (279 x 432 mm)
Original Type
Sheets, books
Document Feeder Capacity
100 sheets
Supported Media Type
Envelopes, plain paper, cards
Supported Media Sizes
ANSI A (Letter) (216 x 279 mm), Legal (216 x 356 mm), Executive (184 x 267 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), B5 (176 x 250 mm), A3 (297 x 420 mm), B4 (250 x 353 mm), A6 (105 x 148 mm), Folio (216 x 330 mm), Statement (139.7 x 215.9 mm), 297 x 1321 mm, Tabloid (279 x 432 mm), 64 x 90 mm
Standard Media Capacity
935 sheets
Max Media Capacity
2005 sheets
Bypass Feeder Capacity
100 sheets
Output Trays Capacity
350 sheets
Document & Media Handling Details
RADF - 100 sheets size: 105 x 148 mm - A3/Ledger (297 x 432 mm) weight: 60 g/m² - 120 g/m²
Multi-purpose tray - 100 sheets size: 64 x 90 mm - 297 x 1321 mm weight: 64 g/m² - 256 g/m²
Input tray - 300 sheets weight: 64 g/m² - 220 g/m²
Input tray - 535 sheets weight: 64 g/m² - 176 g/m²
Output tray - 350 sheets
Speed Details
Copying: up to 35 ppm (A4) - B/W
Copying: up to 35 ppm (A4) - colour
Printing: up to 35 ppm (A4) - B/W landscape
Printing: up to 35 ppm (A4) - colour landscape
Printing: up to 20 ppm (A3) - B/W landscape
Printing: up to 20 ppm (A3) - colour landscape
Scanning: up to 50 ipm - B/W
Scanning: up to 50 ipm - colour
Scanning: up to 17 ipm - B/W duplex
Scanning: up to 17 ipm - colour duplex
Finishing Equipment
Connections
Interfaces
1 x USB 2.0 - 4 pin USB Type B
1 x Gigabit LAN - RJ-45
USB 2.0 host - 4 pin USB Type A
2 x phone line - RJ-11
Security Protocols & Features
LDAP, Secure Print
Operating System Support
Linux, MS Windows Server 2008 R2, MS Windows Server 2012, MS Windows Server 2012 R2, MS Windows Server 2003 (32/64-bits), MS Windows Server 2008 (32/64-bits), MS Windows Vista (32/64 bits), MS Windows 7 (32/64 bits), Windows 8 (32/64-bits), Windows 8.1 (32/64-bits), Apple Mac OS X 10.6 - 10.10
Software Included
ABBYY FineReader Sprint, OKI smartPrintSuperVision, SENDYS Explorer
Power
Voltage Required
AC 230 V (50/60Hz)
Power Consumption Operational
1400 Watt
Power Consumption Standby
120 Watt
Power Consumption Sleep
3 Watt
Miscellaneous
First Copy Out Time B/W
10 sec
First Copy Out Time Colour
10 sec
Included Accessories
Phone cable, cabinet
Consumables Included
1 x toner cartridge (black)
1 x toner cartridge (cyan)
1 x toner cartridge (magenta)
1 x toner cartridge (yellow)
Compliant Standards
GS, EMC
Environmental Standards
Manufacturer Warranty
Service & Support
Limited warranty - 3 years with product registration
Dimensions & Weight
Environmental Parameters
Sound Emission
37 dBA (idle) / 54 dBA (operating)
Min Operating Temperature
10 °C
Max Operating Temperature
32 °C
Humidity Range Operating
20 - 80%
