Raritan Dominion SX DSX2-8 - Console server

Productcode: DSX2-8 | EAN/UPC: 0785813028662

€ 1.619,36 excl.btw

Raritan Dominion SX DSX2-8 - Console server - 8 ports - 1GbE, PPP, serial - 1U

Full CLI-based configuration and auto-configuration
Innovative at-the-rack access
Automatic DTE/DCE serial port detection

Op voorraad: 0 stuk(s)

Levertijd:

Product:
Raritan Dominion SX DSX2-8 - Console server

€ 1959,43 incl. 21% btw € 1619,36excl. 21% btw

Winkelwagen Offerte

Stuur mij een notificatie bij voorraad

Omschrijving

Raritan Dominion SX DSX2-8 - Console server - 8 ports - 1GbE, PPP, serial - 1U

Product features

Full CLI-based configuration and auto-configuration
The SX II offers complete CLI access and management via SSH, Telnet and web-browser, with convenient direct port access methods. Two script-based automatic configuration methods (TFTP server and USB stick) are available for fast installation and configuration changes.
Innovative at-the-rack access
With the Dominion SX II, you get multiple types of local access at-the-rack. This includes Traditional RJ45 serial port, Mini-USB port for laptop connection, and a DVI & USB-based KVM console for connection to a rackmount keyboard tray, or even a KVM switch.
Automatic DTE/DCE serial port detection
For fast installations, the SX II supports straight Cat5 connections to Cisco and other compatible RJ-45 devices, without rollover cables. The SX II can also directly replace the first generation SX with compatible serial device connections.

Specificaties

General

Device Type

Console server

Height (Rack Units)

Processor / Memory / Storage

Processors Installed

1 GHz

Networking

Form Factor

External

Ports Qty

Connectivity Technology

Wired

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, PPP, serial

Network / Transport Protocol

TCP/IP, UDP/IP

Remote Management Protocol

SNMP, Telnet, HTTP, HTTPS, SSH

Capacity

Simultaneous connections: 200

Status Indicators

Power, status

Features

IPv6 support, reset button, IPv4 support

Encryption Algorithm

SSL

Authentication Method

Secure Shell (SSH), RADIUS, PAP, TACACS+, LDAP

Expansion / Connectivity

Interfaces

1 x console - RJ-45
1 x mini-USB
8 x serial - RJ-45
4 x USB - Type A
2 x 100Base-TX - RJ-45
1 x DVI-D

Miscellaneous

Included Accessories

4 rubber feet, rack mount kit

Compliant Standards

UL, FCC Part 15 A, cULus

Power

Power Device

Internal power supply

Installed Qty

Voltage Required

AC 120/230 V (50/60 Hz)

Power Consumption Operational

21 Watt

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C

Humidity Range Operating

20 - 85% (non-condensing)

This data is supplied by 1WorldSync and matched through an automated process. Truedata is not responsible for errors in this data.
