Kenmerken
Interface
PCI Express 4.0
Type geheugen
3D TLC NAND
Component voor
Server/werkplaats
M.2 SSD-grootte
2280 (22 x 80 mm)
Random read (4KB)
280000 IOPS
Random write (4KB)
40000 IOPS
Mean time between failures (MTBF)
2000000 uur
Certificering
CE (Europe): EN55032, EN55024 Class B, RoHS
FCC: CFR Title 47, Part 15, Class B
UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013
BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663
RCM (Australia, New Zealand): AS/NZS CISPR32 Class B
KC RRL (Korea): approval to KN32 Class B, KN 35 Class B
W.E.E.E.: Compliance with EU WEEE directive 2012/19/EC.
TUV (Germany): approval to IEC60950/EN60950
VCCI (Japan): 2015-04 Class B
IC (Canada): ICES-003 Class B
Morocco: EN55032, EN55024 Class B
UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139)
UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS
Energie
Stroomverbruik (lezen)
7 W
Stroomverbruik (schrijven)
4,5 W
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 70 °C
Temperatuur bij opslag
-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Trillingen bij opslag
20 G
Schokbestendigheid
1500 G
Maximale hoogte, in gebruik
3050 m
