General
Device Type
Network adapter
Interface (Bus) Type
PCI Express 4.0 x16
PCI Specification Revision
PCIe 1.1, PCIe 2.0, PCIe 3.0, PCIe 4.0
Networking
Ports
100 Gigabit QSFP56 x 2
Connectivity Technology
Wired
Data Link Protocol
10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 50 Gigabit Ethernet
Data Transfer Rate
100 Gbps
Network / Transport Protocol
TCP/IP, UDP/IP, IPSec, SMB
Features
Firewall protection, MPLS support, DoS attack prevention, firmware upgradable, QoS, PXE support, LSO, LRO, RSS, UEFI support, SR-IOV, Energy Efficient Ethernet, AER, checksum offload support, MSI-X, iSCSI remote boot, Ethernet remote boot, TSS, RoCE, NC-SI, VXLAN, NVGRE, Link Aggregation, TPH, SDN, MSI, DPDK, iSCSI Extensions over RDMA (iSER), VLAN Tagging, ASAP, MCTP over SMBus, NFV, GENEVE support, NVMe-oF
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg, IEEE 1588v2, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3cd
Expansion / Connectivity
Interfaces
2 x 100Gb Ethernet - QSFP56
Miscellaneous
Encryption Algorithm
TLS, 256-bit AES-GCM, 128-bit AES-GCM, AES-XTS
