General
Device Type
Solid state drive - hot-swap
Interface
U.2 PCIe 3.0 x4 (NVMe)
Features
Enhanced Power Loss Data Protection, Thermal throttling, End-to-end data path protection, End-to-end data protection, S.M.A.R.T.
Performance
Drive Writes Per Day (DWPD)
30
Internal Data Rate
2.5 GBps (read) / 2.2 GBps (write)
4KB Random Read
550000 IOPS
4KB Random Write
550000 IOPS
Reliability
Non-Recoverable Errors
1 per 10^17
Expansion & Connectivity
Interfaces
1 x PCI Express 3.0 x4 (NVMe) - U.2 (SFF-8639)
Power
Power Consumption
8 Watt (read) ¦ 13 Watt (write)
Software & System Requirements
OS Required
Red Hat Enterprise Linux 6 x64 Edition, SuSE Linux Enterprise Server 11 x64 Edition, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 7, SuSE Linux Enterprise Server 12, Microsoft Windows Server 2016, VMware ESXi 6.0, VMware ESXi 6.5
Miscellaneous
Compliant Standards
CSA, UL, C-Tick, BSMI CNS 13438, EN 60950-1 Second Edition, RoHS 2011/65/EU, LVD 2006/95/EC, EN55022:2006, WEEE 2002/96/EC, EN55024:1998, CAN/CSA-CEI/IEC CISPR 22:02, FCC CFR47 Part 15 B Class B, AS/NZS 3584, KCC Article 11.1
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (operating)
1000 g @ 0.5 ms
Vibration Tolerance (operating)
2.17 g @ 5-700 Hz
Compatibility Information
Designed For
Lenovo ThinkAgile VX 2U Certified Node (2.5") ¦ Lenovo ThinkAgile VX 2U4N Certified Node (2.5") ¦ Lenovo ThinkAgile VX Certified Node 7Y94 (2.5"), 7Z12 (2.5") ¦ Lenovo ThinkAgile VX3320 Appliance 7Y93 (2.5") ¦ Lenovo ThinkAgile VX3720 Appliance 7Y92 (2.5") ¦ Lenovo ThinkAgile VX7520 Appliance 7Y94 (2.5") ¦ Lenovo ThinkAgile VX7820 Appliance 7Z13 (2.5") ¦ Lenovo ThinkSystem SD530 (2.5") ¦ Lenovo ThinkSystem SN550 (2.5") ¦ Lenovo ThinkSystem SN850 (2.5") ¦ Lenovo ThinkSystem SR630 (2.5") ¦ Lenovo ThinkSystem SR650 (2.5") ¦ Lenovo ThinkSystem SR850 (2.5") ¦ Lenovo ThinkSystem SR860 (2.5") ¦ Lenovo ThinkSystem SR950 (2.5")
