General
Device Type
Solid state drive - hot-swap
Encryption Algorithm
256-bit AES
NAND Flash Memory Type
3D quad-level cell (QLC)
Features
64-layer 3D NAND technology, S.M.A.R.T.
Performance
Drive Writes Per Day (DWPD)
0.09
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
540 MBps (read) / 350 MBps (write)
4KB Random Read
83000 IOPS
4KB Random Write
6500 IOPS
Reliability
Non-Recoverable Errors
1 per 10^17
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s
Power
Power Consumption
2.8 Watt (read) ¦ 6.3 Watt (write)
Miscellaneous
Compliant Standards
TUV, EN 60950, RRL, IEC 60950, IC, RoHS, UL 60950-1 Second Edition, BSMI CNS 13438, RCM, WEEE 2002/96/EC, FCC CFR47 Part 15 B Class B, EN 55032 Class B, KCC KN32 Class B, CISPR 32 Class B, KCC KN35 Class B, Micron Green Standard, VCCI 2015.04 Class B, ICES-003:2016
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (non-operating)
1500 g @ 0.5 ms
Vibration Tolerance (non-operating)
3.13 g @ 5-800 Hz
Compatibility Information
Designed For
Lenovo ThinkSystem SD530 7X21 (2.5") ¦ Lenovo ThinkSystem SN550 7X16 (2.5") ¦ Lenovo ThinkSystem SN850 7X15 (2.5") ¦ Lenovo ThinkSystem SR530 7X07 (2.5"), 7X08 (2.5") ¦ Lenovo ThinkSystem SR550 7X03 (2.5"), 7X04 (2.5") ¦ Lenovo ThinkSystem SR570 7Y02 (2.5"), 7Y03 (2.5"), 7Y04 (2.5") ¦ Lenovo ThinkSystem SR590 7X98 (2.5"), 7X99 (2.5") ¦ Lenovo ThinkSystem SR630 7X01 (2.5"), 7X02 (2.5") ¦ Lenovo ThinkSystem SR645 7D2X (2.5") ¦ Lenovo ThinkSystem SR650 7X05 (2.5"), 7X06 (2.5") ¦ Lenovo ThinkSystem SR665 7D2V (2.5"), 7D2W (2.5") ¦ Lenovo ThinkSystem SR850 7X18 (2.5"), 7X19 (2.5") ¦ Lenovo ThinkSystem SR860 7X69 (2.5"), 7X70 (2.5") ¦ Lenovo ThinkSystem SR950 7X11 (2.5"), 7X12 (2.5"), 7X13 (2.5") ¦ Lenovo ThinkSystem ST550 7X09 (2.5"), 7X10
