General
Display Type
LED-backlit LCD monitor / TFT active matrix
Built-in Devices
USB 3.1 Gen 1 hub
Native Resolution
UWQHD+ 3840 x 1600 at 61 Hz
Colour Support
16.8 million colours
Colour Gamut
100% sRGB, 94% DCI-P3
Response Time
5 ms (grey-to-grey)
Vertical Refresh Rate
29 - 61 Hz
Horizontal Refresh Rate
31 - 99 kHz
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Backlight Technology
LED backlight
OSD Languages
Chinese (traditional), Chinese (simplified), English, German, French, Italian, Swedish, Spanish, Japanese
Features
Auto EcoView, Flicker Free technology, Movie Mode, sRGB Mode, landscape mode, Power Saving Mode, Zero Bright Pixels
Dimensions (WxDxH)
89.39 cm x 24 cm x 41.1 cm - with stand
Audio
Output Power / Channel
1 Watt
Connectivity
Interfaces
DisplayPort (HDCP 1.3) ¦ 2 x HDMI (HDCP) ¦ USB-C ¦ 2 x USB 3.1 Gen 1 upstream (Type B) ¦ USB-C 3.1 Gen 1 upstream/DisplayPort Alt Mode with Power Delivery ¦ 4 x USB 3.1 Gen 1 downstream ¦ Headphones
Mechanical
Display Position Adjustments
Height, swivel, tilt
Height Adjustment
192.7 mm
VESA Mounting Interface
100 x 100 mm
Miscellaneous
Features
VESA interface support
Cables Included
1 x USB-C cable - 2 m ¦ 1 x DisplayPort cable - 2 m ¦ 1 x HDMI cable - 2 m ¦ 2 x USB-A to USB-B cable - 2 m
Compliant Standards
FCC Class B certified, TUV, TUV GS, TUV S, CB, CCC, TUV Ergo, RoHS, WEEE, PSE Mark, cTUVus, China Energy Label Level 2, EPA, VCCI Class B, EAC, China RoHS, RCM, CAN ICES-3 Class B, TUV LBL
Power
Input Voltage
AC 120/230 V (50/60 Hz)
Power Consumption (Typical)
28 Watt
Power Consumption Stand by
0.5 Watt
Software / System Requirements
Included Software
EIZO Screen InStyle
OS Required
Apple macOS Sierra 10.12 or later, Windows 8.1 / 10 (32/64 bits)
Dimensions & Weight
Dimensions & Weight Details
With stand - width: 89.39 cm - depth: 24 cm - height: 41.1 cm - weight: 13.2 kg ¦ Without stand - width: 89.39 cm - depth: 10.98 cm - height: 39.82 cm - weight: 9.5 kg
Environmental Standards
TCO Certified
TCO Certified Displays 8
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80% (non-condensing)
