General
Product Type
LED-backlit LCD flat panel display
Power Consumption Operational
126 Watt
Commercial Use
Yes - digital signage
Combined With
Built-in SoC media player
Operating System
Android OS 11
PC Interface
Serial RS-232, USB-C
Modes
Portrait mode, landscape mode
Picture Enhancements
Blue Light Filter
Display
LCD Display Technology
ADS
Colour Support
1070000000 colours
Display Format
4K UHD (2160p)
Frame Rate & Enhancement Technology
60 Hz Refresh Rate
LCD Backlight Technology
Direct LED
Coating
Anti-glare, 3H Hard, 25% haze
Image Contrast Ratio
1200:1
Dynamic Contrast Ratio
5000:1
Viewing Angle (Vertical)
178 degrees
Backlight Life
50,000 hour(s)
Operation Hours / Days
24 / 7
Features
Dimming Control (DCR), Open Pluggable Specification slot, Crestron Connected Compatible, Flicker free technology, OPS Slot, ViewBoard Cast software, WiFi slot, 1.07 billion colours (8-bit+FRC), blue light reduction
Stands & Mounts
Flat Panel Mount Interface
800 x 600 mm
Video Features
Input Video Formats
480p, 720p, 1080i, 1080p, 480i, 576i, 576p, 4K
Media Player
Supported Video Formats
MPEG-1, MPEG-2, MPEG-4, Xvid, WMV, ASF, AVI, MKV, MOV, VOB, FLV, RM, TS, H.264, RMVB, DAT, TP, TRP, WebM, MPG, MPEG, OGM, 3GP
Supported Audio Formats
MP3, WMA, WAV, AC3, AAC, M4A, MP4
Supported Pictures Formats
BMP, PNG, JPEG
Configuration
ARM Cortex-A55 Quad-Core - 4 GB - 32 GB
Remote Control
Battery Form Factor
AAA type
Audio System
Output Power / Total
16 Watt
Features
Audio Return Channel (ARC)
Speakers
2 x main channel speaker - 10 Watt
Network & Internet Multimedia
LAN Protocol
Fast Ethernet
Connections
Connector Type
3 x HDMI input
RS-232 input
HDMI output
USB-C with 65W Power Delivery
SPDIF output
LAN
USB 2.0
USB 3.0
Miscellaneous
Included Accessories
Remote control, batteries, ViewBoard software, screws, RS232 adapter
Cables Included
HDMI cable - 3 m
USB-C cable - 1.8 m
Compliant Standards
CB, FCC, RoHS, WEEE, cTUVus, REACH, UkrSEPRO, ERP, EAC, RCM, CE/EMC, HDCP 2.2, Mexico Energy label, TPCH, Mexico NOM, CA65, SCIP, Annex II (EU) 2015/863, ICES 003, Green BOM
Sustainability Information
Power
Input Voltage
AC 100-240 V (50 - 60 Hz)
Power Consumption (Off Mode)
0.5 Watt
Manufacturer Warranty
Service & Support
Limited warranty - replace or repair - 5 years - on-site
Dimensions & Weight (Shipping)
Weight (Shipping)
48.15 kg
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% RH
