General
Built-in Devices
GPS / GLONASS / Galileo, Beidou, QZSS
Processor / Memory / Storage
Processors Installed
1 x MediaTek MIPS 24Kec 580 MHz
Networking
Form Factor
Desktop / wall / DIN rail mountable
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, BACnet, RS-485, Modbus, DNP3, RS-232
Network / Transport Protocol
TCP/IP, UDP/IP, IPv4, IPv6, ICMP/IP, NTP, DNS, HTTP, HTTPs, SFTP, FTP, SMTP, ARP, PPPoE, DHCP, OpenVPN, IPSec, PPTP, L2TP, WireGuard
Routing Protocol
BGP, static IP routing, OSPFv2, RIP-1, RIP-2, EIGRP, NHRP, policy-based routing (PBR), VRRP, GRE
Remote Management Protocol
SSH, HTTP, HTTPS, Telnet, SMPP, SNMP 1, MQTT, RADIUS, CLI, Kinesis, SSH-2, TR-069, SNMP 2, SNMP 3, JSON-RPC, Modbus, DHCP
Status Indicators
2G, signal, 4G
Features
Auto APN, auto-uplink (auto MDI/MDI-X), Point-to-Point Protocol (PPP), UPnP, wake on LAN (WOL), NAT support, VoIP passthrough support, connection monitoring, firewall protection, Captive Portal, DHCP relay, DHCP server, Quality of Service (QoS), RADIUS Server, Smart Queue Management (SQM), Wi-Fi Multimedia (WMM) support, automated failover, SSHFS support, Pre-Shared Key (PSK), digital certificates, DMZ support, IPSec NAT-Traversal (NAT-T), DDos attack prevention, port scan prevention, VLAN support, Dynamic Multipoint VPN (DMVPN), SSTP client instance support, router mode, DLMS support, Firmware Over-the-Air (FOTA), SNMP trap, Teltonika Remote Management System (RMS), Networked Transport of RTCM via Internet Protocol (NTRIP), reset button, aluminium housing
Encryption Algorithm
SSL, TLS, 128-bit AES, 192-bit AES, 256-bit AES, Triple DES, CAST5, DES, DESX, IKEv1, IKEv2, RC2
Authentication Method
RADIUS, X.509 certificates, TACACS+
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3az, IEEE 802.11e
IP Telephony
Aerial
Antenna
External detachable
Communications
Mobile Broadband Access
Yes
Mobile Communication Protocol
LTE
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Communications Technology
LTE Cat M1, LTE Cat NB2, LTE Cat NB1, EGPRS
Expansion / Connectivity
Expansion Slots
2 (total) / 2 (free) x SIM card
Interfaces
1 x RS-485 - terminal block
2 x aerial - SMA
1 x RS-232 - terminal block
1 x network - RJ-45
3 x digital input - terminal block
3 x digital output - terminal block
Miscellaneous
Included Accessories
16-pin terminal block, hex key
Compliant Standards
NMEA, IP30, UKCA, EAC, CB, EN 55032:2015+A1:2020+A11:2020, EN 301 489-1 V2.2.3, EN 55035:2017+A11:2020, EN 61000-3-3:2013+A1:2019+A2:2021, EN IEC 61000-3-2:2019+A1:2021, EN 301 489-19 V2.2.1, EN 301 489-52 V1.2.1, EN 61000-4-2:2009, EN 61000-4-3:2020, EN 61000-4-4:2012, IEC 61000-4-3:2020, EN 61000-4-5:2014+A1:2017, EN 61000-4-6:2014, EN IEC 61000-4-11:2020, EN 301 908-1 V15.2.1, EN 301 908-13 V13.2.1, EN 303 413 V1.2.1, EN IEC 62368-1:2020+A11:2020, EN IEC 62311:2020, AS/NZS 62368.1:2022, IEC 62368-1:2018
Power
Power Device
External power adapter
Power Consumption Operational
2 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Humidity Range Operating
10 - 90% (non-condensing)
