General
Product Type
LED-backlit LCD flat panel display
Commercial Use
Yes - digital signage
Operating System
Android OS 10
Modes
Portrait mode, landscape mode
Picture Enhancements
Dynamic contrast enhancement, progressive scan
Display
LCD Display Technology
ADS
Colour Support
1070000000 colours
Display Format
4K UHD (2160p)
LCD Backlight Technology
Direct LED
Image Contrast Ratio
1300:1
Dynamic Contrast Ratio
500000:1
Viewing Angle (Vertical)
178 degrees
Pull-Down Compensation
3:2, 2:2
Display Menu Language
Chinese (traditional), Chinese (simplified), English, German, French, Italian, Polish, Russian, Spanish, Turkish, Arabic, Japanese
Backlight Life
50,000 hour(s)
Commercial Features
HTML5 support, FailOver
Operation Hours / Days
18 / 7
Stands & Mounts
Flat Panel Mount Interface
400 x 400 mm
Video Features
Input Video Formats
1080/60i, 720/60p, 1080/50i, 720/50p, 1080/50p, 1080/60p, 2160/50p, 2160/60p
Supported Computer Resolutions
1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1280 x 720, 1920 x 1080, 1440 x 900, 1280 x 800, 3840 x 2160, 1680 x 1050
Media Player
Supported Video Formats
MPEG-4, AVI, H.264, H.263, MPEG, H.265, VP8
Supported Audio Formats
AAC, HE-AAC
Supported Pictures Formats
BMP, PNG, JPEG
Supported Memory Cards
microSD
Configuration
ARM Cortex-A55 Quad-Core - 3 GB - 16 GB - Mali G52 MC1
Remote Control
Battery Form Factor
AAA type
Audio System
Output Power / Total
20 Watt
Speakers
2 x speaker - 10 Watt
Network & Internet Multimedia
Connections
Connector Type
2 x HDMI input
DVI-I input
2 x USB 2.0
USB 3.0
Audio line-out
Audio line-in
LAN
RS-232C input/output
Infrared input/output
Miscellaneous
Included Accessories
USB dust cover, 3 clampers, logo sticker, screws
Cables Included
IR sensor cable - 1.8 m
RS-232 daisy chain cable
RS232 cable
Compliant Standards
FCC Class A certified, UL, VCCI, CB, RoHS
Power
Input Voltage
AC 100-240 V (50/60 Hz)
Power Consumption Stand by
0.5 Watt
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80% RH (non-condensing)
