The HP HSR6800 Router Series is a portfolio of high-performance WAN services routers, ideal for large-scale data center and campus WAN networks. These routers are built with a multi-core distributed processing architecture that scales up to 420 Mpps forwarding and up to 2 Tbps switch capacity. They deliver robust routing (MPLS, IPv4, IPv6, dynamic routing, nested QoS), security (stateful firewall, IPsec/Dynamic VPN, DoS protection, NAT), full Layer 2 switching, traffic analysis capabilities, and high-density 10 GbE (and 40/100 GbE-ready) WAN interface options, all integrated in a single powerful routing platform. In addition, the HSR6800 Router Series are the first service aggregation routers in the industry to support system virtualization by taking advantage of HP innovative Intelligent Resilient Framework (IRF) technology.
Netwerk
Verzending snelheid
240 Mpps
Beveiliging
MAC-adrestabel
2000000 entries
Energie
Vermogensverbruik (max)
851 W
AC-ingangsspanning
100 - 240 V
Overige specificaties
Prestatiebeheer
command-line interface; out-of-band management; SNMP Manager; Telnet; RMON1; terminal interface (serial RS-232C); Ethernet Interface MIB
Montage
EIA standard 19 in. rack
Gewicht (imperiaal)
25,5 kg (56.2 lbs)
Afmetingen (B x D x H) (Brits)
436,1 x 482,1 x 308,1 mm (17.2 x 19 x 12.1")
Poorten & interfaces
Aansluitingen
(4) SAP slots or (8) HIM slots or (16) MIM slots, or a combination
