General
Host Connectivity
Gigabit Ethernet
Enclosure Type
Rack-mountable - 1U
Total Storage Capacity
32 TB
Max Supported Capacity
32 TB
Installed Devices / Modules Qty
4 (installed) / 4 (max)
Processor / Memory
Processors Installed
1 x Intel Xeon Bronze 3204 1.9 GHz
Features
Registered, HPE SmartMemory
Storage Controller
Interface Type
SATA 6Gb/s / SAS 12Gb/s
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Hard Drive
Type
HDD - hot-swap - 3.5" LFF
Data Transfer Rate
1.2 GBps
Features
Midline, Digitally Signed Firmware
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, GigE
Network Services Compatibility
DNS, DHCP, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Server Message Block 2.0 (SMB 2.0)
Expansion / Connectivity
Expansion Bays
4 (total) / 0 (free) x hot-swap - 3.5" LFF
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x16 (three-quarter-length, full-height) ¦ 1 (total) / 1 (free) x PCI Express 3.0 x8 (three-quarter-length, full-height) ¦ 1 (total) / 1 (free) x FlexibleLOM ¦ 2 (total) / 1 (free) x CPU ¦ 24 (total) / 23 (free) x DIMM 288-pin
Interfaces
4 x Ethernet 1000Base-T ¦ 1 x HPE iLO ¦ 2 x USB 3.0 ¦ 1 x VGA ¦ 1 x HPE iLO (management)
Miscellaneous
Features
Trusted Platform Module (TPM) 2.0
Compliant Standards
WEEE 2002/95/EC
Included Accessories
5 x hot-plug redundant fans, rack rail kit
Power
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Software / System Requirements
Storage Operating System
Microsoft Windows Storage Server IoT 2019 Standard
Software Included
HPE iLO Advanced Premium Security Edition with 1 Year Support
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day ¦ Limited warranty - software - 90 days
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
