General
Printer Type
Label printer - direct thermal / thermal transfer - monochrome
Printer
Print Speed
Up to 300 mm/sec - max speed
Built-in Devices
Status LCD, peeler with liner rewind
Connectivity Technology
Wired
Interface
USB 2.0, LAN, serial, USB host
Max Resolution (B&W)
203 dpi
Language Simulation
Intermec Printer Language (IPL), Intermec Fingerprint, Intermec Direct Protocol, DSim (Datamax Interpreter), ZSim, Extensible Mark-up Language (XML)
Features
Realtime clock, Black Mark sensor, gap sensor, peeler with liner rewind, notch sensor
Barcodes
UCC/EAN-128, ISBT 128, HIBCC, LOGMARS, Postnet, AIAG
RAM
RAM Installed (Max)
256 MB
Technology / Form Factor
SDRAM
Flash Memory
Card Reader
Supported Flash Memory Cards
CompactFlash Card
Media Handling
Media Type
Labels, tickets, continuous labels, tags, fanfold labels
Max Media Size
Roll (12 cm)
Min Media Size (Custom)
25.4 mm
Max Media Size (Custom)
120 mm
Media Sizes
Roll (2.54 - 12 cm)
Max Printing Length
4095 mm
Media Thickness Range
0.06 mm - 0.254 mm
Roll Maximum Outer Diameter
213 mm
Roll Core Diameter
76 mm, 38 mm
Media Feeders
1 x manual - 1 roll - Roll (12 cm)
Networking
Remote Management Protocol
SNMP 3, HTTP, ICMP, IPv6
Expansion / Connectivity
Expansion Slots
2 x expansion slot
Connections
1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x LAN - RJ-45 ¦ 1 x USB host - 4 pin USB Type A
Miscellaneous
Compliant Standards
FCC Class A certified, UL, C-Tick, cUL, EN 55022 Class A
Power
Power Device
Power supply - internal
Voltage Required
AC 120/230 V
Frequency Required
50/60 Hz
Power Consumption Operational
400 Watt
Power Consumption Stand by
20 Watt
Software / System Requirements
Software Included
Drivers & Utilities, Intermec InterDriver, Intermec PrintSet
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
Dimensions & Weight
