General
Product Form Factor
Tower - 4U
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: German / region: Germany
Processor / Chipset
CPU
Intel Core i7 (14th Gen) i7-14700
Clock Speed
2.1 GHz (P-core) / 1.5 GHz (E-core)
Max Turbo Speed
5.4 GHz (P-core) / 4.2 GHz (E-core)
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Cache Memory
Installed Size
L3 Cache - 33 MB
RAM
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
4 (Total) / 2 (empty)
Features
Unbuffered, dual channel memory architecture
Configuration Features
2 x 16 GB
Hard Drive
Interface Type
PCI Express 4.0
Features
HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Storage Controller
Controller Interface Type
SATA 6Gb/s
Optical Storage
Card Reader
Supported Flash Memory Cards
SD Memory Card
Monitor
Graphics Controller
Graphics Processor
Intel UHD Graphics 770
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Input Device
Keyboard
Localization & Layout
German
Mouse
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 15
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25"
1 (total) / 1 (free) x external 5.25" Slim Line
2 (total) / 2 (free) x internal 3.5"
1 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 1 (free) x PCIe 5.0 x16
1 (total) / 1 (free) x PCIe 3.0 x4 (x1 mode)
1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode)
1 (total) / 1 (free) x PCIe 3.0 x4
3 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode)
1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module)
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support)
6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging)
1 x audio line-in
1 x audio line-out
2 x DisplayPort 1.4
1 x LAN (Gigabit Ethernet)
1 x USB 3.2 Gen 1
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen
Power
Voltage Required
AC 90-269 V (50/60 Hz)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English / German
Software
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% RH (non-condensing)
