General
Device Type
Security appliance
Bundled Services
3 years Basic Security Suite
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol
TCP/IP, L2TP, IPSec, PPPoE, SMTP, FTP, DHCP, DNS, POP3, DDNS
Routing Protocol
OSPF, BGP-4, RIP-1, RIP-2, static IP routing, policy-based routing (PBR)
Remote Management Protocol
SNMP 2, SNMP 3, HTTP, CLI
Performance
Firewall throughput: 40 Gbps ¦ VPN throughput: 10 Gbps ¦ Antivirus throughput: 9 Gbps ¦ IPS throughput: 13 Gbps ¦ Unified Threat Management (UTM) throughput: 8 Gbps ¦ Connection rate: 160000 connections per second
Capacity
Concurrent connections: 7500000 ¦ Virtual interfaces (VLANs): 1000 ¦ Authenticated users: unlimited ¦ Branch office VPN tunnels: 5000 ¦ Mobile IPSec VPN tunnels: 10000 ¦ Mobile SSL VPN tunnels: 10000 ¦ Mobile L2TP VPN tunnels: 10000 ¦ QoS hardware queues: 8
Features
NAT support, load balancing, Syslog support, Stateful Packet Inspection (SPI), DoS attack prevention, content filtering, DiffServ support, IPv6 support, High Availability, deep inspection, HTTPS proxy, Quality of Service (QoS), IPSec NAT-Traversal (NAT-T), VPN failover, WAN failover, DHCP server, DNS proxy, FTP proxy, HTTP proxy, POP3 proxy, SMTP proxy, TCP proxy, DHCP relay, DHCP client, proxy firewall
Encryption Algorithm
DES, Triple DES, RSA, IKE, SSL, 128-bit AES, 192-bit AES, 256-bit AES, SHA-2
Authentication Method
SecurID, RADIUS, LDAP, internal user database, Active Directory, VASCO token authentication
Compliant Standards
IEEE 802.3ad (LACP)
IP Telephony
Expansion / Connectivity
Expansion Slots
2 (total) / 2 (free) x expansion slot
Interfaces
8 x 1000Base-T - RJ-45 ¦ 1 x serial ¦ 2 x USB
Miscellaneous
Included Accessories
Rack mount kit
Compliant Standards
ICSA IPSec certified, ICSA Firewall certified, CB, CSA NRTL/C, RoHS, FIPS 140-2, WEEE, REACH, Common Criteria EAL4+, IPv6 Ready
Manufacturer Selling Program
WatchGuard Trade-Up Program
Power
Power Device
Internal power supply - hot-plug
Voltage Required
AC 120/230 V
Power Consumption Operational
75 Watt
Software / System Requirements
Software Included
WatchGuard Dimension
Manufacturer Warranty
Service & Support
Limited warranty - advance hardware replacement - 3 years ¦ Technical support - 3 years ¦ New releases update - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
