General
Device Type
Security appliance
Processor / Memory / Storage
Networking
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Network / Transport Protocol
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, PPPoE, DHCP
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR)
Remote Management Protocol
SNMP 2, SNMP 3, CLI
Performance
Firewall throughput: 6 Gbps ¦ Full Deep Packet Inspection (DPI) throughput: 800 Mbps ¦ Application throughput: 2 Gbps ¦ IPS throughput: 2 Gbps ¦ Anti-malware throughput: 1.1 Gbps ¦ Firewall throughput (IMIX): 1.6 Gbps ¦ SSL throughput: 500 Mbps ¦ VPN throughput: 3 Gbps
Capacity
New sessions per second: 40000 ¦ Connection / user qty: 500000 ¦ DPI connections: 250000 ¦ Maximum number of access points: 64 ¦ VPN tunnels (site-to-site): 1500 ¦ IPSec VPN connections: 500 ¦ SSL VPN users: 2 ¦ Virtual interfaces (VLANs): 512
Features
NAT support, VPN support, load balancing, DoS attack prevention, antivirus analysis, Intrusion Prevention System (IPS), URL filtering, deep inspection, DDos attack prevention, Stateful switchover (SSO), anti-spam protection, anti-malware protection, Quality of Service (QoS), DHCP server, bandwidth control, Link Aggregation Control Protocol (LACP), NetFlow, IPFIX
Encryption Algorithm
DES, Triple DES, MD5, SHA-1, 128-bit AES, 192-bit AES, 256-bit AES
Authentication Method
RADIUS, internal user database, Active Directory, XAUTH authentication
Compliant Standards
IEEE 802.1p
IP Telephony
VoIP Protocols
SIP, H.323 v3, H.323 v4, H.323 v1, H.323 v2, H.323 v5
IP Telephony Features
VoIP gatekeeper support, VoIP outbound bandwidth management
Expansion / Connectivity
Interfaces
2 x 10GBase-X - SFP+ ¦ 4 x 1000Base-X - SFP (mini-GBIC) ¦ 12 x 1000Base-T - RJ-45 ¦ 2 x USB - Type A ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x management - RJ-45
Miscellaneous
Compliant Standards
FCC Class A certified, UL, TUV GS, VCCI, C-Tick, BSMI, ICSA Firewall certified, cUL, NOM, ICSA Antivirus, CB, RoHS, FIPS 140-2, KCC, WEEE, ANATEL, VPNC certified
Pricing Type
SonicWALL Secure Upgrade Plus Program (3 years option)
Power
Power Device
Internal power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
86.7 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
