General
Device Type
Security appliance
Bundled Services
1 year TotalSecure
Built-in Devices
Status LCD
Processor / Memory / Storage
Networking
Form Factor
Rack-mountable
Connectivity Technology
Wired
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Network / Transport Protocol
TCP/IP, PPTP, L2TP, ICMP/IP, IPSec, PPPoE, DHCP
Routing Protocol
OSPF, RIP-1, RIP-2, BGP, static IP routing, policy-based routing (PBR)
Remote Management Protocol
SNMP 2, SNMP 3, HTTP, HTTPS, CLI
Performance
Firewall throughput: 20 Gbps ¦ Application throughput: 11.5 Gbps ¦ IPS throughput: 11.5 Gbps ¦ Anti-malware throughput: 5 Gbps ¦ VPN throughput: 11.5 Gbps ¦ Forwarding performance (IMIX): 5.5 Gbps ¦ Latency: 17µs
Capacity
Virtual interfaces (VLANs): 512 ¦ VPN tunnels (site-to-site): 10000 ¦ VPN client licences: 2000 ¦ New connections per second: 130000 ¦ Connection / user qty: 1500000 ¦ DPI connections: 1250000
Status Indicators
Power, test mode, alarm
Features
NAT support, VPN support, load balancing, LDAP support, Stateful Packet Inspection (SPI), DoS attack prevention, manageable, High Availability, Intrusion Prevention System (IPS), URL filtering, deep inspection, DDos attack prevention, anti-malware protection, Quality of Service (QoS), RADIUS support, DHCP server, reset button, bandwidth control, hot swappable dual fans, Link Aggregation Control Protocol (LACP), NetFlow, IPFIX
Encryption Algorithm
DES, Triple DES, MD5, SHA-1, FIPS 140-2, 128-bit AES, 192-bit AES, 256-bit AES
Authentication Method
RADIUS, LDAP, Active Directory, XAUTH authentication
Compliant Standards
IEEE 802.1p
IP Telephony
Communications
Supported Flash Memory Cards
SDHC Memory Card
Expansion / Connectivity
Expansion Slots
1 (total) / 1 (free) x expansion slot
Interfaces
1 x 1000Base-T (management) - RJ-45 ¦ 2 x USB - Type A ¦ 1 x management - RJ-45 ¦ 8 x 1000Base-T - RJ-45 ¦ 8 x 1000Base-X - SFP (mini-GBIC) ¦ 4 x 10GBase-X - SFP+
Miscellaneous
Cables Included
1 x network cable ¦ 1 x serial cable
Compliant Standards
FCC Class A certified, UL, TUV GS, VCCI, C-Tick, BSMI, cUL, NOM, CB, RoHS, KCC, WEEE, ANATEL
Power
Power Device
Internal power supply - hot-plug
Voltage Required
AC 120/230 V (50/60 Hz)
Power Consumption Operational
300 Watt
Software / System Requirements
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
