General
Device Type
Radio access point
Networking
Form Factor
Wall / ceiling mountable
Connectivity Technology
Wireless
Data Transfer Rate
1300 Mbps
Line Coding Format
DBPSK, DQPSK, CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
Remote Management Protocol
SNMP 3, SNMP 2c, CLI
Frequency Band
2.4 GHz, 5 GHz
Performance
WLAN throughput: 1.6 Gbps
Capacity
Maximum number of configured SSIDs: 16
Features
VLAN support, DiffServ support, manageable, MAC address filtering, IPv6 support, firmware upgradable, Mesh networking, Wi-Fi Multimedia (WMM) support, Multiple SSID support, 2T2R MIMO technology, Maximum Ratio Combining (MRC), 3T3R MIMO technology, Low Density Parity Check (LDPC), rogue access point detection, DHCP client, Cyclic Delay Diversity (CDD), Maximum Likelihood Demodulation (MLD), security lock slot (cable lock sold separately), ZyXEL One Network (ZON), MU-MIMO technology, Unscheduled Automatic Power Save Delivery (U-APSD), beamforming technology, packet aggregation A-MPDU, packet aggregation A-MSDU, SU-MIMO technology, Smart Connect, Fast Roaming, low end sensitivity improvements (LESI), time domain channel smoothing, Layer 2 isolation
Encryption Algorithm
TLS, PEAP, TTLS, WPA, WPA2, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise, WEP, EAP-SIM, EAP-AKA
Authentication Method
RADIUS, Radio Service Set ID (SSID), Extensible Authentication Protocol (EAP), EAP-FAST
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ac Wave 2, IEEE 802.3au, IEEE 802.11ab
Aerial
Expansion / Connectivity
Interfaces
2 x 1000Base-T (PoE+) - RJ-45 ¦ 1 x console
Miscellaneous
Included Accessories
Mounting screws, wall/ceiling mounting plate
Compliant Standards
EN 61000-3-2, EN 61000-3-3, EN55024, FCC Part 15 B, FCC Part 15 C, IEC 60950-1, EN 60950-1, FCC Part 15 E, BSMI CNS 13438, EN 60601-1-2, EN 300 328, BSMI CNS 14336-1, EN 301489-17, EN 301 489-1, LP0002, EN 301 893, EN 55032
Power
Power Over Ethernet (PoE) Supported
PoE+
Power Device
External power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Dimensions & Weight (Shipping)
Environmental Parameters
Min Operating Temperature
-20 °C
Max Operating Temperature
60 °C
Humidity Range Operating
10 - 90% (non-condensing)
