General
Device Type
Radio access point
Processor / Memory / Storage
Processors Installed
710 MHz
Networking
Form Factor
Wall mountable
Connectivity Technology
Wireless
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
Frequency Band
2.4 GHz, 5 GHz
Performance
Maximum data rate (2.4 GHz): 300 Mbps
Maximum data rate (5 GHz): 867 Mbps
Capacity
Wireless clients per Wi-Fi radio: 200
Wireless clients: 400
Features
Manageable, DFS support, wall mountable, Mesh networking, Wi-Fi Multimedia (WMM) support, RADIUS support, ceiling mountable, 802.1x authentication, MU-MIMO technology, SU-MIMO technology, Authentication, Authorization and Accounting (AAA), security slot (Kensington security lock compatible)
Encryption Algorithm
AES, TLS, PEAP, TTLS, WPA2, WPA3
Authentication Method
RADIUS, MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.11r, IEEE 802.11ac Wave 2
Aerial
Expansion / Connectivity
Interfaces
1 x 1000Base-T (PoE) - RJ-45
1 x 1000Base-T (PoE output) - RJ-45
2 x 1000Base-T - RJ-45
1 x pass-through - RJ-45
Miscellaneous
Included Accessories
Torx security screw, mounting bracket
Compliant Standards
VCCI, ICES-003, FCC Part 15.247, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, ARIB STD-T66, ARIB STD-T71, EN 300 328, EN 50385, FCC OET Bulletin 65c, EN 301 489-1, RSS-247, EN 301 893, CAN/CSA-C22.2 No. 60950-1, EMI Class B, EN 301 489-17
Power
Power Over Ethernet (PoE) Supported
PoE
Power Consumption Operational
8.5 Watt
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
10 - 90% (non-condensing)
