General
Device Type
Switch - 18 ports - smart
Enclosure Type
Rack-mountable
Ports
16 x 10/100/1000 (PoE+) + 2 x Gigabit SFP (uplink)
Power Over Ethernet (PoE)
PoE+
Performance
Forwarding performance (64-byte packet size): 26.78 Mpps
Switching capacity: 36 Gbps
Capacity
MSTP instances: 16
VLANs supported: 256
ACL rules: 512
Buffer capacity (MB): 4.1
MAC Address Table Size
8192 entries
Jumbo Frame Support
9216 bytes
Routing Protocol
IGMPv2, IGMP, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Authentication Method
Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2)
Features
BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, MAC address filtering, Broadcast Storm Control, Multicast Storm Control, ACL support, QoS, Cable Diagnostics Function, fanless, LACP support, LLDP support, Port Security, DHCP client, Energy Efficient Ethernet, MIB, dual firmware images, NDP, GVRP, 802.1x authentication, ToS, DSCP support, VLAN management, LLDP-MED, Guest VLAN, UDP, STP loop guard, WRR, HOL Blocking Prevention, loopback detection, Telnet server, Unknown Storm Control, BPDU Guard, CDP, DAD, TCP support, auto voice VLAN, Auto MDIX
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Status Indicators
System, link/activity/speed
Expansion / Connectivity
Interfaces
16 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W
2 x 1000Base-X SFP uplink
Power
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
160.2 Watt
Miscellaneous
Rack Mounting Kit
Included
Compliant Standards
C-Tick, UL 60950, CSA 22.2, FCC CFR47 Part 15 A
Localisation
United Arab Emirates, Indonesia, Israel, South Africa, Vietnam, Ukraine, Egypt, Thailand, Philippines, Korea, Russia, Switzerland, Turkey, European Economic Area
Dimensions & Weight
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 3 years - response time: next business day
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
10 - 90% (non-condensing)
Min Storage Temperature
-20 °C
Max Storage Temperature
70 °C
Humidity Range Storage
10 - 90% (non-condensing)
